Seema AS63A high-precision vibration meter, acceleration 0.1~ 199.9m/s2
The piezoelectric ceramic accelerometer provides 0.1-199 m/s ² acceleration, 0.1-199 mm/s velocity and 001-1.999 mm displacement measurement range for accurate vibration testing. The error is ± 10%, and AC signal output and full scale display are supported.
SMART SENSOR
AS63A
-
DUBAN DB22-VM260A12 Vibrator, displacement D 0.001~ 12.0mm
$ 532.16 -
DUBAN DB22-VM260B Vibrator, three-parameter display, displacement 0.001~ 4.0mm
$ 412.57 -
LANDTEK VM-6370 Vibration Meter (Enhanced)
$ 389.57 -
DUBAN DB22-VM260A Vibration instrument, displacement D 0.001~ 4.0mm
$ 332.85 -
LANDTEK VM-6380-2 Vibration Meter (Dual Channel)
$ 489.23
SMART SENSOR AS63A Vibration meterSpecifications
| LIST | VALUE |
|---|---|
| Measurement method | Pottery and porcelain accelerometers |
| Acceleration Measurement range | 0.1~199.9m/s² |
| Speed Measurement range | 0.1~199.9mm/s |
| Displacement Measurement range | 0.001~1.999mm |
| Acceleration frequency range | 10Hz~1KHz(LO)，1KHz~15KHz(HI) |
| Speed frequency range | 10Hz ~ 1KHz (LO) |
| Displacement frequency range | 10Hz ~ 1KHz (LO) |
| Measurement error | ±10%Hz±2digits |
| data output | AC signal output Peak (full scale display) |
| display | 3.5 digits LCD display |
| Automatic range switching | Yes. |
| Backlight display function | Yes. |
| Automatic shutdown function | Yes. |
| Operating Temperature | 0~40℃ |
| Power | 9V battery |
| Weight | 147g |
| Dimensions | 183*67*30mm |
| Encasement method | Aluminum Encasement |
| Standard outer box capacity | 10PCS |
| Standard outer box size | 45*32*55cm |
| Standard gross weight | 14.17KG |
SMART SENSOR AS63A Vibration meter Packing list
Vibration meter X1, original battery X1, long probe x1, short probe x1, factory certificate X1, warranty card X1, manual X1, portable toolbox x1.
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
