Hypertherm CZ-S Vibration meter, miniature vibration measurement instrument
ISO 2954 compliant, designed for on-site mechanical vibration measurement with a high-performance accelerometer. Acceleration, speed and displacement measurements are supported with USB, RS-232 and Bluetooth data output options.
HBO
CZ-S
CZ-Z
CZ-J
-
Pen Vibration Meter AMITTARI AV-160P Digital Display Portable Pen Vibration Meter
$ 210.19 -
Seema AS63A high-precision vibration meter, acceleration 0.1~ 199.9m/s2
$ 104.09 -
Vibrometer AMITTARI AV-160A detects imbalances and deviations in moving machinery
$ 309.85 -
LANDTEK VM-6380-3 Vibration Measuring Instrument (Three Channel)
$ 673.22 -
DUBAN DB22-VM260A Vibration instrument, displacement D 0.001~ 4.0mm
$ 332.85
Applications
Applied to periodic motion measurement to detect imbalance and deviation of moving machinery. It is specially designed for on-site measurement of various mechanical vibrations to provide data for quality control, running time and prior equipment maintenance.
Overview
* Conforms to international standard ISO2954 for periodic motion measurement to detect imbalance and deviation .
* Designed for on-site measurement of various mechanical vibrations to provide data for quality control, running time and prior equipment maintenance.
* Use high-performance accelerometers to achieve accurate and reproducible measurements.
* With AC signal output, it is convenient for auscultation and recording.
* Optional earphones can be used as a stethoscope.
* Use "USB data line output" and "RS-232 data line output" to communicate with PC.
* Provide Bluetooth data output option.
* Sensor piezoelectric acceleration sensor
Optional
1. Earphone stethoscope
2. USB or RS-232 cable and software
3. Bluetooth communication and software
HBO CZ-S Vibration meterSpecifications
| LIST | VALUE |
|---|---|
| Acceleration Measurement range | 0.1~ 200M/s ² peak |
| Measurement range | 0.01~ 200mm/s True RMS |
| Measurement range | 0.001~ 2.0mm peak-peak |
| Acceleration Frequency range | 10Hz~ 1kHz 10Hz~ 10kHz (x10 mode for bearing inspection) |
| Frequency range | 10Hz~1k Hz |
| Frequency range | 10Hz~1KHz |
| Precision | +/- (5% n + 2) words |
| output | 2.0 v AC load resistance 10 k |
| MAX Maximum Hold | Automatic shutdown |
| Battery voltage indication | Low voltage prompt |
| data output | USB, RS-232, Bluetooth |
| Working conditions | Temperature: 0~ 50 ℃ Humidity: < 90% RH |
| power supply | 4 AA batteries |
| Dimension | 148*72*34 mm |
| weight | 140G (without battery) |
HBO CZ-S Vibration meter Packing list
Host X1, magnetic suction seat X1, Piezoelectric Sensors X1, probe (cone) X1, probe (ball) X1, portable case, instruction manual
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
