1. Features
*This instrument is a battery-powered portable measuring instrument, using the principle of eddy current. The measurement method conforms to the international standard ISO2360 and the national standard GB4957. It adopts computer technology, non-destructive testing technology and many other professional technologies to accurately measure the thickness of the measured object without damaging it.
*NF-type probe can measure the thickness of the insulating covering layer on the non-magnetic metal substrate, such as paint, plastic, rubber coating on the surface of aluminum, copper, zinc, non-magnetic stainless steel and other materials, and can also measure the thickness of aluminum or aluminum alloy materials Anodized layer thickness.
*The spring guide sleeve probe with wear-resistant hard metal probe can not only measure on hard or rough surfaces, but also ensure that the probe has constant pressing force and stable sampling value.
*Digital display, wide measuring range and high resolution.
2. Specification
Display: 4-digit 10mm LCD
Lantai CM-8825 N coating Thickness Gauge test range: 0~1250um
Other measuring ranges need to be ordered separately.
Resolution: 0.1um/1um
Measurement accuracy: ±1~3%n or ±2.5um
Measurement mode: single measurement and continuous measurement.
It has the conversion function of metric and imperial units to realize um/mil conversion.
With a standard RS232C interface.
Power supply: 4 AAA batteries.
Operating conditions: temperature 0~40°C, humidity <80%
Dimensions: 126x65x27mm
Weight: 81g (excluding battery)
Standard accessories:
Carrying case.................................. 1 piece
Aluminum base.................................... 1 piece
Instruction manual................................1 copy
Calibration diaphragm
CM50.................................1 piece
CM100.................................1 piece
CM300.................................1 piece
CM500.................................1 piece
(The actual thickness of the diaphragm is marked on the diaphragm)
Optional accessories:
RS232C communication cable and software
