Japan's ANESTIWATA ANESTIWATA Air Compressor is very popular in the Chinese market, and the familiarity is also very high. In this issue, Beichao made a clear comparison of three models of oil-free scroll Air Compressors of the same type in combination with actual users. It mainly involves 3 models, including SLPJ-15L, SLPJ-22L and SLPJ-37L scroll oil-free Air Compressors. It can be seen that the three Air Compressors all adopt the sliding vane compression method, the exhaust pressure is ≤800 10³Pa0.65~0.8, and the noise control and specifications are the same. The difference is that the displacement of the three models is different, the SLPJ-15L is 175L/min, and the other two models are 405L/min. This can actually be distinguished from the model number.
Please see the following table for specific similarities and differences:
| model |
ANEST IWATA SLPJ-15L oil-free scroll Air Compressor |
ANEST IWATA SLPJ-22L oil-free scroll Air Compressor |
ANEST IWATA SLPJ-37L oil-free scroll Air Compressor | |
|---|---|---|---|---|
| type | oil-free scroll | oil-free scroll | oil-free scroll | |
| compression method | sliding vane | sliding vane | sliding vane | |
| Exhaust pressure | ≤800 10³Pa 0.65~0.8 | ≤800 10³Pa 0.65~0.8 | ≤800 10³Pa 0.65~0.8 | |
| displacement | 175L/min | 405L/min | 405L/min | |
| Tank volume | 15L | 22L | 37L | |
| air interface | Rc3/8 | Rc3/8 | Rc3/8 | |
| Output Power | 1.5KW (HP) | 3.7KW (HP) | 3.7KW (HP) | |
| power supply | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | |
| Noise value | 50±3dB(A) | 50±3dB(A) | 50±3dB(A) | |
| Dimensions | 500*600*765mm | 500*600*765mm | 500*600*765mm | |
| weight | 105kg | 115kg | 115kg | |
| Operation control method | Pressure Switch | Pressure Switch | Pressure Switch | |
