Waiting for the autoclave to cool down after a sterilization cycle can be the most time-consuming phase, and if the throughput in your lab is high, you may want to consider available cooling options to speed up the autoclave cycle.
Fan cooling (external)
This method uses a powerful externally mounted fan to help speed up the cooling phase of the autoclave cycle. External fans are controlled via a touchscreen controller.
Fan cooling (internal)
The method has a built-in fan inside, which creates turbulent flow. This is one of the effective methods used to cool the system, which needs to be used in conjunction with a water cooling jacket. This option is only available on front loaders and is ideal for situations where large fluid loads need to be handled quickly. Cooling times can be up to 70% faster than standard autoclaves if the autoclave is equipped with fan cooling (jackets), air ballasts and load sensing timing.
Applicable to: front loader
automatic drain
When the pressure in the autoclave chamber reaches a certain level during the cooling phase of the cycle, any remaining water in the chamber will be expelled. This method can be selected on any cycle and it will greatly reduce the time it takes to cool the chamber down to a temperature where it is safe to open the door. This method can only be used in autoclaves where the heater is located inside the chamber and is most efficient when used with a water cooling coil.
Suitable for: Bench Top, Compact, Top Loader, Front Loader
Water cooling (coil)
Cooling water is passed through coils located around the outdoor chamber, reducing cooling time.
Suitable for: top loaders, front loaders
Water cooling (jacket)
This method of cooling circulates the cold water in direct contact with the outside of the autoclave chamber, which can be further enhanced if internal fan cooling is installed.
Suitable for: top loaders, front loaders
cyclone cooling
This option uses an Air Compressor to significantly reduce cycle times, which provides significant benefits for laboratories handling large volumes of bottled liquids that require rapid sanitization. This option is available free of charge, but requires water cooling (jacket) and gas ballast options.
Suitable for: top loaders, front loaders
