Thermal shock chambers are required for testing equipment in the metals, plastics, rubber, electronics and other materials industries. For testing the structure of materials or composites.
This kind of environmental detection equipment can withstand the continuous environment of extremely high temperature and extremely low temperature in an instant, so as to detect the chemical change or physical damage caused by the thermal expansion and contraction of the sample in the shortest time.
Precaution:
1. Do not open the door to take samples during the test. The heat can burn your hands.
2. Do not test explosive samples.
3. After the experiment is over, wait for the machine to cool down before taking out the sample.
4. Turn off the cooling water in time after the experiment.
Steps:
1. Check before starting the machine
2. Whether the cooling water is turned on.
3. Whether the test sample is put into the test box.
4. Whether each power supply is connected well.
Open:
Open the metal door under the control panel, press the power switch, and the control panel lights up.
operate:
1. After turning on the power, directly touch the setting prompt on the control panel.
2. First click "Program Settings", and set the experimental conditions required for the samples to be tested in sequence according to the prompts.
3. When performing a sample test under the same conditions as the previous experiment, click the "Established" button and select the existing procedure to continue.
4. After all conditions are set, return to the "Run" interface and click the "Start" button.
closure:
1. After the test is completed, turn off the power switch.
2. Take out the experimental samples half an hour after the end of the experiment.
