Germany HTechMT CO300 Destructive Thickness Gauge

Germany HTechMT CO300 Destructive Thickness Gauge with 50x Microscope, CO300 Destructive Thickness Gauge is suitable for Coating thickness measurement on plastic, wood, metal, concrete, Glass or Miscellaneous Non-metallic substrates.

Brand

SKU: NB010230

HTechMT

Model

CO300

Get Quote

HTechMT shopSE

Information

Datasheet Video Catalog Manual

What else did others buy

Defelsko PosiTector 6000 FS3 Coating Thickness Gauge Iron metal substrate (steel, iron, etc.) Split probe type

$ 1456.00
LEEB Leeb252C Metal Coating Thickness Gauge magnetic Induction/eddy Current Range 0~1500μm

$ 254.00
Defelsko FNS conventional with line probe

$ 1157.00
Defelsko PosiTector 6000 NS3 zinc layer thickness Measurement Instrument nonconductive Coating thickness Measurement Instrument

$ 1535.00
JFL QDX film multi-purpose Detector film thickness, Hardness, adhesion and other performance detection

$ 607.00

Genuinegoods

HTechMT CO300 Destructive Thickness GaugeOverview
Specifications
Comments
FAQs

CO300

Destructive Thickness Gauge

Introduction

The CO300 destructive Thickness Gauge uses a carbon steel cutter to test the thickness of single or multi-layer coatings on plastic, wood, metal, concrete, glass or other non-metallic substrates.

Features

- Easy to operate

- Compact and lightweight

- wide field of view

- Highly bright LED lights and clear scale lines

- Built-in screwdriver

- 50x microscope

- Metric and Imperial

Accessories

Accessory model	describe	Measuring range	angle	coefficient
CO300-1	Cutter No.1	20-2000 Î¼m (1-80 mils)	45Â°	20 Î¼m (1 mils)
CO300-4	Cutter No.4	10-1000 Î¼m (0.5-40 mils)	26.6Â°	10 Î¼m (0.5 mils)
CO300-6	Cutter No.6	2-200 Î¼m (0.1-8 mils)	5.7Â°	2 Î¼m (0.1 mils)
CO300-2	Microscope components

HTechMT CO300 Destructive Thickness GaugeSpecifications

LIST	VALUE
Measurement principle	destructive
Measurement range	2~200μm
Machine Weight	260g
Machine size	1008021mm

HTechMT CO300 Destructive Thickness Gauge Packing list

CO300 host, Encasement box, No. 6 knife, 2 AA batteries, marker, manual and certificate of conformity

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

We want to test the coating thickness of the concrete. We have bought the ultrasonic principle before, but because the substrate is rough, the measurement is uncertain, and the data fluctuates very much. Is there a needle probe?

[A]

Needle probe is destructive, through the destruction of coating thickness, the use of Pythagorean theorem to calculate the coating depth, the error of this equipment is mainly from human error, mainly human reading error and scratch coating error

[Q]

Is the film thickness test of plastic substrate and Glass substrate OK?

[A]

Destructive can ignore the substrate

[Q]

Resin Coating thickness measurement on graphite is OK?

[A]

Testing substrate is hard, and the Color between the substrate and the coatings should be clearly distinguished, so as to see the bottom material and the coatings under magnifying glass Otherwise, if the Color is the same, you can't distinguish which layer, each layer of coating and substrate, you can't read

[Q]

How does this CO300 destructive thickness gauge work? It doesn't work a little bit.

[A]

Hello, for the specific operation method, please refer to the detailed steps of the operation manual. The manual is downloaded from the "Operation Manual" column on the right side of the product page.

[Q]

Can all destructive thickness gauges be used for inspection in the ASTMB487 standard?

[A]

Not necessarily, but this CO300 destructive thickness gauge can be considered.
