Defelsko PosiTector 6000 F90S1 Coating Thickness Gauge
Defelsko Defelsko PosiTector 6000 F90S1 Coating Thickness Gauge is a 90 ° miniature probe, right angle probe for measurement in low headroom areas. With minimal measurement tip and good film Measurement accuracy, it is suitable for measurement of small parts, close to the edge or hard to contact areas.
Defelsko PosiTector 6000 F90S1 Coating Thickness GaugeKey Spec.
Measurement principle
Magnetic Induction
Measurement range
0~1150μm
margin of error
±3%
PosiTector 6000 F90S1 Coating Thickness Gauge
Details
9 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
