AMITTARI AV-160D 3D triaxial vibrator
AMITTARI AV-160D 3D Triaxial Vibration Meter Digital Display 3D Triaxial Vibration Meter with Three Axis Piezoelectric Vibration Sensors, AV-160D Vibration Tester with X, Y, Z Axis or Three Axis, 3D Triaxial Vibration Meter AV-160D Test accuracy is +/- 5% + 2 words.
AMITTARI AV-160D 3D triaxial vibratorKey Spec.
Displacement Measurement range
0.001~4.000mm
Acceleration Measurement range
0.1~400.0m/s²
Speed Measurement range
0.1~400mm/s
AV-160D 3D triaxial vibrator
Details
5 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
