KORNO GT-903-Y3 (H2S, O2, EX) standard three-in-one Gas Detector
Simultaneously detect combustible gas, hydrogen sulfide, oxygen, explosion-proof mark Ex ia ⅱ C T4 Ga, detection accuracy ≤ +/- 3%, Linearity ≤ +/- 1%, Sampling method pump suction.
KORNO
GT-903-Y3(H2S,O2,EX)
GT-903-Y3(CO,O2,EX)
GT-903-Y3(CO,H2S,O2)
GT-903-Y3(CO,H2S,EX)
-
HUIRUIPU HRP-B1000-CO Carbon monoxide Gas Detector 0-1000ppm/1ppm
$ 141.00 -
Empaer APEG-D-CH4 (4G) Volkswagen Series Stationary Methane Detector
$ 344.00 -
HONEYEAGLE HNAG1000-SO2 Online sulfur dioxide Detector 0-20PPM
$ 509.00 -
BH-60-Cl2 Fixed Chlorine Gas Detector with display + alarm
$ 257.00 -
GUOYUGRA GY/VGD-200-CH5N-G (0-50ppm) Methylamine Detector
$ 817.00
Introduction
GT-903 pump-suction compound Gas Detector is suitable for gas concentration detection in various industrial environments and special environments. It adopts imported electrochemical\infrared gas sensor and microcontroller technology, with fast response speed, high measurement accuracy and stability And repeatability is good, the performance of the whole machine is at the domestic (CN) professional level, various parameters can be customized by users, and the operation is simple. Built-in 4000mA high-capacity polymer rechargeable battery, super long standby time; 2.4-inch industrial-grade color screen, good display of various technical indicators and gas concentration values, historical data can be viewed on the screen, with storage, data export, temperature and humidity detection, etc. Function.
Features
KORNO GT-903-Y3(H2S,O2,EX) Gas DetectorSpecifications
| LIST | VALUE |
|---|---|
| Detection gas | H2S、O2、EX |
| range | 100ppm、0~30%vol、0~100%LEL |
| resolution | 0.01ppm，0.01%vol |
| temperature and humidity | Optional accessories, temperature detection range: -40~120 ℃, humidity detection range: 0~100% RH |
| Sampling method | Pump suction |
| Detection Accuracy | ≤±3% |
| linearity error | ≤±1% |
| Response time | T90≤20s |
| Zero drift | ≤±1%(F.S/年) |
| recovery time | ≤20s |
| Sexual repeability | ≤±1% |
| data storage | Real-time storage and Timer storage can be set; single channel can store 30800 groups of data |
| Explosion-proof sign | Ex ia Ⅱ C T4 Ga |
| Shell material | ABS+PC |
| Protection class | IP65 |
| Operating Temperature | -30~60℃ |
| Environment humidity | 0~95% RH non-condensing |
| Operating Pressure | -30Kpa ~ 200Kpa |
| Power | 4000mA Rechargeable Polymer Battery |
| Dimensions | 180*85*55mm |
| Execution standards | GB3836.1-2010、GB3836.4-2010 |
KORNO GT-903-Y3(H2S,O2,EX) Gas Detector Packing list
host X1, USB charger X1, calibration cover X1, instrument case X1, manual X1, certificate X1, warranty card X1.
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
