KORNO MOT500-H2S-Y Online hydrogen sulfide alarm instrument 0-50ppm
H2S, range 0~50ppm, resolution 0.01ppm, Response time T90 ≤ 20s, Linearity ≤ +/- 1%, detection accuracy ≤ +/- 3%, explosion-proof mark CNEx16.0547, Protection level IP65
KORNO
MOT500-H2S-Y
-
KORNO GT-903-Y2 (CO, EX) Standard 2-in-1 Gas Detector
$ 416.00 -
KORNO GT-903-N2-Y Pump Suction Nitrogen Detector, Range 0-99.99% VOL
$ 470.00 -
Baoshi'an BH-90-NO2 Nitrogen Dioxide Gas Alarm Instrument 0~20ppm
$ 226.00 -
GUOYUGRA GY/VGD-200-C2CL4-G (0-50ppm) tetrachloroethylene Detector
$ 419.00 -
KORNO GT903-BL-O3 portable ozone Detector, detection range 0.001-5ppm
$ 615.00
Introduction
MOT500 online hydrogen sulfide Detector is suitable for hydrogen sulfide gas concentration detection in various environments. It adopts imported electrochemical gas sensor and microcontroller technology, with fast response speed, high measurement accuracy, good stability and repeatability, and the whole machine The performance is at the domestic (CN) professional level.
Features
KORNO MOT500-H2S-Y Hydrogen sulfide DetectorSpecifications
| LIST | VALUE |
|---|---|
| Detect gas | H2S |
| Range | 0~50ppm |
| resolution | 0.01ppm |
| Response time | T90≤20s |
| Linearity | ≤±1% |
| detection Accuracy | ≤±3% |
| Zero drift | ≤ +/- 1% (F. S/year) |
| recovery time | ≤20s |
| Repeatability | ≤±1% |
| expansion gas | Supports 1-6 Sensors (optional) |
| Explosion-proof sign | CNEx16.0547 |
| Protection level | IP65 |
| production license | Guangdong 00001052 (CMC metrology authentication) |
| Humidity | Optional accessories, temperature detection range: -25~ 60 ℃, Humidity detection range: 0~95% RH |
| Sampling method | Diffusion, flow, pump suction optional |
| Installation method | Wall-mounted, pipeline, circulation |
| Operating temperature | -30~50℃ |
| Environmental humidity | 0~95% RH non-condensing |
| Operating Pressure | 0~100Kpa |
| Power Supply | 24VDC（12~30VDC） |
| Dimension | 200*149*79mm |
| Weight | 1.5Kg |
| execution standard | GB3836.1-2010、GB3836.2-2010 |
| receiving device | User computer, control alarm, PLC, DCS, mobile phone, tablet computer, etc. are optional |
| Alarm mode | On-site sound and light alarm, external alarm, remote Controller alarm, computer data collection software alarm, mobile app notification, SMS alarm optional |
| Shell material | Die casting aluminum + sand blasting oxidation/fluorocarbon paint, explosion-proof and anti-corrosion |
| optional range | 0~50、100、500、1000、2000、5000ppm |
KORNO MOT500-H2S-Y Hydrogen sulfide Detector Packing list
host X1, calibration cover X1, manual X1, certificate X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
