DINGDING DM100-O2 Oxygen Gas Detector 0-30% Vol
DINGDING DM100-O2 Oxygen Gas Detector adopts natural diffusion method to detect oxygen concentration, with explosion-proof design, DM100-O2 Oxygen Gas Detector is suitable for explosion-proof, toxic gas leakage rescue, underground pipelines or mines and other places, Measurement range 0-30% Vol.
DINGDING
DM100-O2
-
KORNO GT-903-CH4-Y (infrared 1%) methane Detector, measuring range 0-1000PPM
$ 1038.00 -
Empaer SPES-O3 series handheld ozone concentration Detector
$ 567.00 -
HUIRUIPU HRP-T1000-O2 Oxygen Gas Detector (No Display No Light)
$ 172.00 -
GUOYUGRA GY/VGD-200-HF-G (0-10ppm) Hydrogen Fluoride Detector
$ 568.00 -
HONEYEAGLE HNAG1000-NH3 Fixed Ammonia Gas Detector 0-15000PPM
$ 856.00
Introduction
DM100 oxygen Detector is an intrinsically safe instrument that can continuously detect the concentration of toxic, harmful, flammable and explosive gases in the operating environment. It is suitable for explosion-proof, toxic gas leakage rescue, underground pipelines or mines and other places, which can effectively ensure that the life safety of staff is not infringed and production equipment is not lost.
DM100 oxygen Detector detects gas concentration by natural diffusion, and adopts imported electrochemical sensor (combustible gas is catalytic combustion), which has excellent sensitivity and good repeatability; It is widely used in metallurgy, power plants, chemical industry, mines, tunnels, tunnels, underground pipelines and other places to effectively prevent the occurrence of poisoning accidents.
peculiarity
Non-slip design, sturdy and durable
Two-level triple alarm (sound, light, vibration), not easy to ignore
Large screen (backlit) numbers, character display, instantaneous values, peaks
Self-test the display, battery, sensor, sound and light alarm function when turned on or when needed
Maintenance is low
DINGDING DM100-O2 Gas DetectorSpecifications
| LIST | VALUE |
|---|---|
| Detect gas | Oxygen O2 |
| Range | 0~30%vol |
| detection Accuracy | ＜±1.5%F.S |
| resolution | 0.1%Vol |
| Response time | ≤15s |
| Sensors Life | 24 months |
| Sensors principle | electrochemistry |
| Power Supply | 3.6V lithium-ion rechargeable battery |
| Sampling method | diffusion |
| Operating Time | Use lithium-ion batteries to work continuously for 15h |
| Alarm mode | Sound and light alarm |
| direct reading | Instantaneous value, peak value, battery Voltage, TWA, STEL |
| Explosion-proof sign | Exd Ⅱ C T4 |
| Protection level | IP45 |
| Shell material | ABS+PC |
| Operating temperature | -10~45℃ |
| Environmental humidity | 5~90%RH |
| Low alarm point | 19.5%vol |
| High alarm point | 23.5%vol |
| Dimension | 130*72*32mm |
| Weight | 220g |
DINGDING DM100-O2 Gas Detector Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
