JingTian RVDV-1 Digital Rotational Viscometer

JINGTIAN RVDV-1 digital display Rotational Viscometer 40 million mPa·s 99.9rpm

JINGTIAN RVDV-1 digital display Rotational Viscometer Viscosity range is 80~40,000,000mPa·s, measurement accuracy is ± 1% FS, RVDV-1 Rotational Viscometer standard R2, R3, R4, R5, R6, R7 six rotors.

Brand

SKU: NB020597

JingTian

Model

RVDV-1

Get Quote

JingTian shopSE

Information

Datasheet Video Catalog Manual

What else did others buy

FANGRUI SNB-1 Digital Rotational Viscometer 1~ 2,000,000mPa·s

$ 501.00
HBDV-1T Digital Rotational Viscometer Viscosity 800~104 million mPa·s

$ 1966.00
FANGRUI instrument NDJ-5T Digital Rotational Viscometer with PT100 temperature probe

$ 629.00
NIRUN DV-79 Digital Viscometer Viscosity Range 1-1 million cP

$ 974.00
Huino, a small number of sample adapters, rotors

$ 441.00

Genuinegoods

JingTian RVDV-1 Digital Rotational ViscometerOverview
Specifications
Comments
FAQs

RVDV-1

Digital Rotational Viscometer

Introduction

The LCD of Shanghai JINGTIAN RVDV-1 digital display rotary viscometer can display viscosity, shear rate, shear stress, speed, temperature, percentile torque, rotor number and the maximum measurable value of the selected rotor at the current speed. Viscosity value etc. It is a digital display rotary viscometer with a measuring range of 80 to 40,000,000 mPa·s .

Shanghai JINGTIAN RVDV-1 digital display rotary viscometer

Dimensions

Dimensions of digital display viscometer 2 Dimensions of digital viscometer 1

JingTian RVDV-1 Digital Rotational ViscometerSpecifications

LIST	VALUE
Display	digital display
Measuring range	80~40000000mPa·s
Rotor Specifications	R2#、 R3#、R4#、R5#、R6#、R7#
Reproducibility	±0.5%F.S
Measurement Accuracy	±1%
Power	Dedicated power adapter (input 100~240V 50~60Hz)
Rotor speed	0.1~99.9rpm
Display information	Viscosity, rotational speed, temperature, percentile torque, rotor number and the maximum Viscosity value that can be measured at the current rotational speed of the selected rotor, etc
Speed control method	CVT

JingTian RVDV-1 Digital Rotational Viscometer Packing list

Host X1, protection frame X1, rotor X1 (sleeve), base and horizontal adjustment bolt X1, lifting frame and lifting mechanism X1, special power adapter X1, wrench X1, RTD temperature probe X1, RS232 standard output interface X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

I would like to inquire about silicon nitride ceramics for 3D printing. The viscosity of the slurry, so the viscosity is also different, and the parameters are adjusted because the Solid content is different We want rheology and viscosity measurement in one

[A]

Recommend RVDV-1, this one can measure silicon nitride ceramics

[Q]

Similar to doing B timeout, which rotational viscometer is suitable for applying to the belly?

[A]

This is a coupling agent. According to the Measuring method of the Chinese Pharmacopoeia, RVDV-1 is recommended for the coupling agent.

[Q]

Digital Single Cylinder Viscometer (Maximum Range 20% -90%) GB/T 2794-2022 "Adhesive viscosity determination, single cylinder rotational viscometer method"

[A]

Our Viscometers are all digital single cylinders (the maximum range is 20% -90%). This is just a big standard. Our Viscometers meet the specific model. It depends on what glue you make, what material you want to measure, and the viscosity range.

[Q]

What is the viscosity of imitation stone paint? Can this be used?

[A]

The viscosity value of imitation stone paint is 3~ 8Pa · s, which can be used.

[Q]

Do you have Carbomer's swirl/spin viscometer?

[A]

Carbomer, also known as acrylic cross-linked Resin, this sample can be measured with an RVDV-1 or RVDV-2 Viscometer
