NBCHAO.Com SN: NB000209
DongRu DR260 Coating Thickness Gauge
DR260 platings Thickness testing instrument is a professional nondestructive magnetic coating Thickness testing instrument for measuring the thickness of platings on the surface of magnetic metal materials. Measurement range of this platings Thickness detection instrument is 0~1250 microns.
DongRu DR260 Coating Thickness GaugeKey Spec.
Measurement principle
Magnetic Induction
Measurement range
0 ~ 1250µm
margin of error
±1~3%
DR260 Coating Thickness Gauge
Details
2 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
