BYK 3666 Byko-Test 8500 Enhanced magnetic/nonmagnetic Thickness Gauge
BYK 3666 dual-use Film Thickness Gauge is a byko-test 8500 enhanced magnetic/nonmagnetic dual-use Film Thickness Gauge, BYK 3666 dual-use Film Thickness Gauge has single and continuous two measurement modes, BYK 3666 dual-use dry paint film thickness Measurement Instrument The measurement range is 0~2000μm.
BYK 3666 Byko-Test 8500 Enhanced magnetic/nonmagnetic Thickness GaugeKey Spec.
Measurement principle
Magnetic Induction + eddy Current
margin of error
±2%
3666 Byko-Test 8500 Enhanced magnetic/nonmagnetic Thickness Gauge
Details
3 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
