DUORUI DR-650-H2 Hydrogen Gas Detector Range: 0~1000PPM
DUORUI Hydrogen Gas Detector DR-650-H2 is used for continuous detection of hydrogen concentration in the Operating Environment, with a range of 0~1000ppm. DR-650-H2 Hydrogen Detector adopts OLED LCD screen, which can record alarm information and concentration value.
DuoRui
DR-650-H2
-
GUOYUGRA GY/VGD-200-C4H10-G Fixed isobutane Gas Detector Infrared 0-2% Vol
$ 941.00 -
Empaer SPES-CO series handheld carbon monoxide concentration Detector
$ 245.00 -
Empaer AATL-CH2O (sound and light alarm) Pathfinder series Fixed Formaldehyde Detector
$ 612.00 -
HUIRUIPU HRP-T1000-CL2 Chlorine Gas Detector (No Display No Light)
$ 204.00 -
GUOYUGRA GY/VGD-200-SiF4-G (0-10ppm) silicon tetrafluoride Detector
$ 879.00
Overview
DR-650 series portable single Gas Detector (hereinafter referred to as the equipment) is a portable gas detection and alarm instrument that can continuously detect the gas concentration in the workplace environment. The equipment uses natural diffusion to detect the surrounding ambient gas, which has the following characteristics:
• Good imported gas sensor, with excellent sensitivity and good repeatability;
• Embedded microcomputer control, simple operation, complete functions and high reliability;
• Graphic LCD display, Chinese menu, intuitive and clear;
• Built-in sound, light and vibration alarm, high-low alarm value can be adjusted;
• Alarm information and alarm concentration can be recorded;
• The shell is made of high-strength engineering plastics, with high strength and good hand feel.
The design, manufacture and inspection of this product comply with the following national standards:
GB 12358-2006 "General Technical Requirements for Ambient Gas Detection and Alarm Instruments in Workplaces";
GB 15322.3-2003 Combustible Gas Detectors – Part 3: Portable combustible Gas Detectors.
DuoRui DR-650-H2 Gas DetectorSpecifications
| LIST | VALUE |
|---|---|
| Sensors principle | Electrochemistry |
| Detect gas | H2 |
| Sampling method | diffusion |
| Range | 0~1000ppm |
| Humidity | <95%RH |
| service life | 2 to 3 years (determined by Sensors) |
| Protection level | IP65 |
| alarm point | High and low alarm point |
| Response time | 60s |
| Resolution | 1PPM |
| operating temperature | -20~50℃ |
| display error | ≤±5%F.S |
| Operating Time | ≥100h |
| Weight | 150g |
| Dimensions | 110*70*30mm |
| display content | Time + electricity + gas name + gas concentration value |
| Display | OLED LCD screen |
DuoRui DR-650-H2 Gas Detector Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
