JINGHONG DKB-2215 Thermostatic Bath
JINGHONG DKB-2215 Low temperature Thermostatic Bath Temperature range -20~99 ℃, working tank material stainless steel, working tank size 300 * 250 * 200mm, pump Flow rate 4L/min, Power 1650W, Power supply Voltage AC 200V 50Hz, Dimension 505 * 420 * 865mm.
JingHong
DKB-2215
-
SDPTOP DC-4020 Low Temperature Thermostat -40~95 ℃/20L
$ 3289.00 -
Shangtian Jingyi DC-1030N Low Temperature Circulating Bath, precision circulating constant temperature Water Tank -10 ℃/30L
$ 3155.00 -
LEPTO BC206E Bath Thermostat Circulator
Login -
Shangtian Jingyi DC-2010 Low Temperature Thermostatic Bath Cyclic refrigeration Thermostatic Bath -20 ℃/10L
$ 1377.00 -
FANGRUI HDC1006N (W) Horizontal Low Temperature Thermostat Temperature range -10~100 ℃
$ 738.00
Overview
It is used for colleges and universities, industrial and mining enterprises and scientific research units to do low-temperature precision constant temperature and auxiliary heating or refrigeration.
Features
Using microcomputer intelligent thermostat, it can set and measure the temperature with dual digital display and PID self-tuning function, and the temperature control is accurate and reliable.
Stainless steel liner and top cover
Modular refrigeration unit, with delayed start, high-low pressure multiple protection
Environmentally friendly refrigerants are used to effectively save energy
Optional cut-in printer or RS-485 communication interface [optional]
It can be equipped with SMS monitoring and alarm system to monitor the operation status of the equipment in real time through mobile phones.【Optional】
Serial models
| Model | Studio size | power | Pump flow | Temperature control range |
| DKB-1906 | 210*160*180mm | 900W | 4L/min | 1~99℃ |
| DKB-2006 | -10~99℃ | |||
| DKB-2206 | 1050W | -20~99℃ | ||
| DKB-2306 | 1660W | -30~99℃ | ||
| DKB-1915 | 300*250*200mm | 1500W | 10L/min | 1~99℃ |
| DKB-2015 | 1590W | 4L/min | -10~99℃ | |
| DKB-2215 | 1650W | -20~99℃ | ||
| DKB-2310 | 250*200*200mm | 1500W | -30~40℃ | |
| DKB-2410 | 1500W | 10L/min | -40~40℃ |
JingHong DKB-2215 Thermostatic BathSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | -20~99℃ |
| Tank Material | stainless steel |
| Tank Size | 300*250*200mm |
| Flow rate of pump | 4L/min |
| Power | 1650W |
| Power supply Voltage | AC 200V 50Hz |
| Dimensions | 505*420*865mm |
JingHong DKB-2215 Thermostatic Bath Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
