SANFA DHG-9240 electric thermostatic Drying Oven 250L
Temperature range RT + 10~250 ℃, Temperature Fluctuation +/- 1 ℃, Temperature resolution 0.1 ℃, Temperature uniformity +/- 2 ℃, Volume 225L, Interior size 500 * 600 * 750mm
sanfa-
HUITAI DZF-6500 Vacuum oven with vacuum pump, heating in 500L volume
$ 6600.00 -
HUITAI DZF-6050 Vacuum oven 2 stencil plates can be extracted, volume 50L
$ 660.00 -
Kenton KH-25A digital display electric drying oven with independent temperature limiter
$ 274.00 -
YIHENG DZF-6034 Vacuum Oven chemical special, temperature control RT + 10~200 ℃
$ 963.00 -
BOZHEN BZ-TR-24H Intelligent environmental protection soil sample Drying Oven
$ 5036.00
Application
It is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.
Features
※The inside and outside of the cabinet are welded with high-quality steel plates, the surface is electrostatically sprayed, the working room is made of mirror stainless steel or sprayed with high temperature resistant silver paint, the door is equipped with observation windows or double door structure, the shape is novel, beautiful and energy-saving.
※Microcomputer intelligent digital display temperature controller, accurate and reliable temperature control, simultaneously displays the set temperature and the temperature in the box, with alarm functions for overheating, leakage, sensor failure, and timing function. (Optional intelligent LCD temperature controller).
※A low-noise fan and a suitable air duct are used to form a hot air circulation system, and the dry hot air is directly dried and sterilized by the heated object.
※In addition to the above functions, the upgraded liquid crystal display temperature controller also has programmable temperature control, can be equipped with RS-485 interface, can be connected to a Recorder and a computer, and can record the change of temperature parameters (optional).
Model
| model | volume | power | Temperature control range |
| DHG-9030(A) | 30 | 500 | RT+10-250 |
| DHG-9070(A) | 70 | 1000 | RT+10-250 |
| DHG-9140(A) | 140 | 1500 | RT+10-250 |
| DHG-9240(A) | 225 | 2000 | RT+10-250 |
| DHG-9101-0(A) | 43 | 500 | RT+10-300 |
| DHG-9101-1(A) | 70 | 1000 | RT+10-300 |
| DHG-9101-2(A) | 140 | 1500 | RT+10-300 |
| DHG-9101-3(A) | 225 | 2000 | RT+10-300 |
| Other parameters | |||
| temperature resolution | 0.1°C | ||
| temperature fluctuation | ±1℃ | ||
| temperature uniformity | ±2°C (test point is 100°C) | ||
| Carrier | 2pcs (standard configuration) | ||
| Timer Range | 1-9999min | ||
| Voltage | 220V 50Hz | ||
| Remarks: A is stainless steel liner | |||
| Unit: L, W, °C | |||
sanfa DHG-9240 Electric thermostatic Drying OvenSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | RT+10~250℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±2℃ |
| Volume | 225L |
| Interior size | 500*600*750mm |
| Chamber material | Spray high temperature resistant silver paint |
| Shelf (std.) | 2pcs |
| Enclosure Material | Good steel plate welded, surface electrostatic spray |
| Timer | 1~9999min |
| Power | 220V 50Hz |
| Input Power | 2000W |
| Dimensions | 630*750*1200mm |
| Communication interface | RS-485 (optional) |
sanfa DHG-9240 Electric thermostatic Drying Oven Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
