SANFA DHG-9101-0A electric thermostatic Drying Oven 43L/stainless steel
SANFA DHG-9101-0A Electric thermostatic Drying Oven Temperature range RT + 10~300 ℃, volume 43L, Interior size 350 × 350 × 350mm, Chamber material stainless steel, shelf (std.) 2pcs, Power 500W
sanfa-
Kenton 101-0A digital Electric Forced Air Drying Oven 43L with independent temperature limiter
$ 299.00 -
HUITAI BPG-9070A precision blast dryer, volume 80L with test hole 50mm
$ 665.00 -
YIHENG BPG-9156B programmable precision Forced Air Drying Oven 175L/1650W
$ 1103.00 -
Kenton KH-55T digital electric air blowing dryer 250 ℃/136L with independent temperature limiter
$ 938.00 -
Kenton 101-1AS digital display electric Forced Air Drying Oven, stainless steel inner tank 300 ℃/70L
$ 411.00
Application
It is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.
Features
※The inside and outside of the cabinet are welded with high-quality steel plates, the surface is electrostatically sprayed, the working room is made of mirror stainless steel or sprayed with high temperature resistant silver paint, the door is equipped with observation windows or double door structure, the shape is novel, beautiful and energy-saving.
※Microcomputer intelligent digital display temperature controller, accurate and reliable temperature control, simultaneously displays the set temperature and the temperature in the box, with alarm functions for overheating, leakage, sensor failure, and timing function. (Optional intelligent LCD temperature controller).
※A low-noise fan and a suitable air duct are used to form a hot air circulation system, and the dry hot air is directly dried and sterilized by the heated object.
※In addition to the above functions, the upgraded liquid crystal display temperature controller also has programmable temperature control, can be equipped with RS-485 interface, can be connected to a Recorder and a computer, and can record the change of temperature parameters (optional).
Model
| model | volume | power |
| DHG-9101-0(A) | 43L | 500W |
| DHG-9101-1(A) | 70L | 1000W |
| DHG-9101-2(A) | 140L | 1500W |
| DHG-9101-3(A) | 225L | 2000W |
| same parameters | ||
| Voltage | 220V 50Hz | |
| Temperature control range | RT+10-300℃ | |
| temperature resolution | 0.1°C | |
| temperature fluctuation | ±1℃ | |
| temperature uniformity | ±2°C (test point is 100°C) | |
| Carrier | 2pcs | |
| Timer Range | 1-9999min | |
| Remarks: A is stainless steel liner | ||
sanfa DHG-9101-0A Electric thermostatic Drying OvenSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | RT+10~300℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±2℃ |
| Volume | 43L |
| Interior size | 350*350*350mm |
| Chamber material | stainless steel |
| Shelf (std.) | 2pcs |
| Enclosure Material | Good steel plate welded, surface electrostatic spray |
| Timer | 1~9999min |
| Power | 220V 50Hz |
| Input Power | 500W |
| Dimensions | 620*560*540mm |
| Communication interface | RS-485 (optional) |
sanfa DHG-9101-0A Electric thermostatic Drying Oven Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
