INESA WRS-1B Digital Melting point meter 320 ℃

Using photoelectric automatic detection and PID adjustment technology to provide high accuracy melting point measurement. Equipped with color LCD screen, it supports automatic display of initial and final melting temperatures, and automatic recording of melting Linear dispersion. RS232/USB interface, suitable for capillary tubing samples specified in pharmacopoeia, adjustable heating rate

Brand

SKU: NB027952

INESA

Model

Price

$ 1470.00

Promotion

Service

The delivery and service By NBchao.Com

Get Quote

INESA shopSE

Information

Datasheet RFQ Contract Video Catalog

What else did others buy

INESA WRX-2S Thermal Analyzer

$ 4431.00
INESA INESA SGW-630 Automatic image Melting point meter

$ 4035.00
SUOGUANG WRX-5A Microscopic melting point Tester, Monocular Microscope 40X magnification

$ 1941.00
INESA SGW X-4 Melting point meter

$ 601.00
SUOGUANG WRS-1U Automatic Melting point meter Measurement range Room temperature~ 400 ℃ with USB interface

$ 1446.00

Genuinegoods

INESA WRS-1B Melting point meterOverview
Specifications
Comments
FAQs

WRS-1B

Melting point meter

Features

It adopts photoelectric automatic detection, color LCD screen display, numeric keypad input of different types of instruments, can be equipped with one or three capillaries for sample measurement, automatically calculates the average melting point, has automatic display of initial melting and final melting, and automatically records the melting curve.

The temperature system uses platinum resistance with high linearity as the detection element, and adopts PID adjustment technology to improve the accuracy and reliability of the melting point.

By establishing a communication interface, the working parameters can be printed or saved, and the instrument uses the capillary specified by the pharmacopoeia as the sample tube.

INESA WRS-1B Melting point meterSpecifications

LIST	VALUE
Temperature range	RT+~320℃
Measuring method	automatic
Temperature Resolution	0.1℃
Heating rate	0.2/0. 5/1/1 5/2/3/4/5 ℃/min
error of indication	±0.4℃(≤200℃)；±0.7℃(>200℃)
Repeatability	±0.3℃(1.0℃/min)
linear Heating rate error	±10％
processing power	1 root
Capillary tubing size	Outer diameter is 1.4mm; Inner diameter is 1.0mm; Length is 90mm.
Sample height	3mm
Display mode	5.6 Color LCD display
Calibration method	Multipoint calibrated
Interface	RS232/USB
Printer model	RD-TH32-SC (optional)
Power Supply	220V±22V 50Hz±1HZ
Dimension	360290170mm
Net Weight of instrument	9kg

INESA WRS-1B Melting point meter Packing list

host X1, manual X1, certificate X1, warranty card X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

Calibrate is to do all 3 points, does that mean?

[A]

Three points refer to three points within 100, 100 to 200, and above 200.

[Q]

Can the INESA WRS-1B digital Melting point meter meet the JB/T6177 standard?

[A]

Applicable, please consult the customer service of the mall for details about the JB/T6177 standard.
