TAISITE MFLC-36/13P Experimental muffle furnace 1300 ℃/36L
TAISITE MFLC-36/13P experimental muffle furnace is a program type temperature control muffle furnace, Temperature range 300~1300 ℃, MFLC-36/13P adopts imported program temperature control digital display, with 40 steps program operation function, designed 400 * 300 * 300mm size furnace.
TaiSiTe
MFLC-36/13P
-
YIHENG SX2-10-12NP muffle furnace (programmable Box-Type Resistance Furnace) 1200 ℃ design temperature
$ 1653.00 -
YIHENG SX 2 - 2.5-12 NP muffle furnace 1200 ℃ design temperature, input power 2.5KW
$ 1008.00 -
BENTING CSX2-12-12 Box-Type Resistance Furnace 1200 ℃/30L
Login -
Shengli SLQ1400-50 Atmosphere Furnace 1300 ℃ Volume 80L
Login -
BENTING CSX-4-10 Box-Type Resistance Furnace 1000 ℃/7L
Login
Benefits:
Integrated design, light and compact structure.
Vacuum-formed polycrystalline mullite fiber furnace chamber for effective heat insulation.
Parallel side-opening furnace doors keep the hot end away from the operation
Open the door and cut off the power, and the power recovery delay to ensure safety.
The double-case body is air-insulated and has a low surface temperature.
Exhaust device, which is conducive to ashing.
The high-precision microcomputer thermometer is well combined with the precision sensor, and the temperature is accurate.
Dedicated function keys enable temperature setting.
Auxiliary menu, realize overlift alarm, deviation correction, menu lock, overlift preventer.
Safety: over-lift alarm, menu lock, over-lift prevention, door opening and power failure, power recovery delay.
Comparison of MFLC ceramic fiber muffle furnace series parameters
| Model | Single-stage type(D) | MFLC-3/13D | MFLC-8/13D | MFLC-12/13D | MFLC-18/13D | MFLC-27/13D | MFLC-36/13D |
| Programmatic (P) | MFLC-3/13P | MFLC-8/13P | MFLC-12/13P | MFLC-18/13P | MFLC-27/13P | MFLC-36/13P | |
| Touch Type(T) | MFLC-3/13T | MFLC-8/13T | MFLC-12/13T | MFLC-18/13T | MFLC-27/13T | MFLC-36/13T | |
| Performance | Operating temperature range | 300～1300℃ | |||||
| Control accuracy | ±1℃ | ||||||
| Temperature resolution | 1℃ | ||||||
| Heating time | ≤30min | ||||||
| composition | Exterior | Cold-rolled steel plate, surface resistant coating | |||||
| Furnace body | Polycrystalline mullite fibers | ||||||
| Furnace size | 200*150*10 | 250*180*180 | 300*200*200 | 300*250*250 | 300*300*300 | 400*300*300 | |
| Exhaust holes | The outer diameter is φ22, and the inner diameter is φ18 | ||||||
| heater | Silicon carbon rods | ||||||
| Heating power | 3KW | 4KW | 6KW | 8KW | 12KW | 14KW | |
| Controls | Thermostats | Type D: Single-stage temperature control digital display P type: imported program temperature control digital display T type: 7-inch color touch screen program temperature control | |||||
| Control mode | Use a microcomputer PID control | ||||||
| How to set it up | D/P type: touch five button action, digital display setting T-type: finger touch tap setting | ||||||
| How it is displayed | D/P type: double line LED digital display T type: color LCD screen display | ||||||
| timing | 0~999.9 hours | ||||||
| Run the function | Type D: Fixed-value operation P/T type: Fixed-value operation The program runs | ||||||
| Program mode | Type D: Single-stage operation Type P: Program runs 4 curves 40 steps Type T: Program runs 50 steps | ||||||
| sensor | Type S thermocouples | ||||||
| Ancillary features | D/P type: Correction function Gating function Type T: Correction function Gating function Real-time curve recording U disk data export | ||||||
| Safety devices | Overcurrent leakage protection switch | ||||||
| Specifications | Dimensions (W*D*H mm) | 520*660*813 | 550*698*893 | 570*749*911 | 620*749*963 | 670*760*1031 | 670*849*1033 |
| Outer packing size (W*D*H mm) | 695*785*1070 | 725*835*1150 | 745*885*1170 | 795*885*1220 | 845*885*1290 | 845*985*1290 | |
| Content volume | 3L | 8L | 12L | 18L | 27L | 36L | |
| Net weight/gross weight kg | 40/50 | 60/70 | 70/85 | 80/95 | 90/105 | 100/115 | |
| Power supply (50/60Hz) rated current | AC220V/13.6A | AC220V/18.2A | AC380V/9.1A | AC380V/12.2A | AC380V/18.2A | AC380V/21.3A | |
TaiSiTe MFLC-36/13P Ceramic muffle furnaceSpecifications
| LIST | VALUE |
|---|---|
| maximum temperature | 1300℃ |
| Temperature range | 300~1300℃ |
| Heating Elements | silicon carbide rod |
| Furnace material | Polycrystalline mullite fiber |
| Furnace Volume | 36L |
| Heating power | 14KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤30min |
| Temperature control instrument | Imported program temperature control digital display |
| Thermocouple | S-type Thermocouple |
| Furnace size | 400*300*300mm |
| Power supply Voltage | AC380V/21.3A 50/60Hz |
| Dimension | 670*849*1033mm |
| Weight | 100kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter Should be 22, Inner diameter Should be 18 |
| Temperature control instrument | Using microcomputer PID control |
| setting method | Tap five button action, digital display settings |
| Display mode | Dual LED digital display |
| Timer Range | 0~999.9h |
| Operational Features | Fixed value operation, program operation |
| Program Mode | Program Run 4 Linear dispersion |
| Additional features | Correction function, gating function |
| Safety Devices | Overcurrent leakage protection switch |
| packing size | 845*985*1290mm |
| Gross Weight | 115kg |
TaiSiTe MFLC-36/13P Ceramic muffle furnace Packing list
Host X1, operation manual X1, certificate of conformity X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
