JENCO 3621 (set) online pH oxidation reduction controller
The measurement range of JENCO3621 (set) online pH oxidation reduction controller is 0.00~14.00pH, and the measurement accuracy and resolution of this model are +/- 0.01pH +/- 1 word and 0.01pH respectively. 3621 (set) is a pH oxidation reduction controller that can measure pH or ORP value.
JENCO
3621 (set)
Features
Standard 1/8 DIN waterproof body design correction value power-off memory function.
pH or ORP values can be measured.
4~20mA reversible, with isolated current output, the output range can be set by the user.
2 sets of pH relay control, control point/hysteresis width can be set by the user.
It has the function of automatic temperature compensation.
| Optional | ||
| pH electrode | IP-600-1 | In the field of wastewater treatment with high turbidity, it can be used in a long-term environment of 80 degrees |
| IP-600-10 | In the field of ordinary carved water treatment, there is no temperature compensation | |
| IP-600-9PT | In the field of ordinary carved water treatment, automatic temperature compensation | |
| IP-600-3C | Pure water, ultrapure water measurement | |
| ORP electrodes | IR-500-8 | In the field of general wastewater, -2000mV~2000mV |
| IR-500-9 | In the field of general wastewater, -1000mV~1000mV | |
| Mounting bracket | 009A | 1 meter pool mounting bracket |
| Sealed box | 011-200-00 | Dial-mounted |
| 012-200-00 | Wall-mounted | |
JENCO 3621 (set) pH oxidation controllerSpecifications
| LIST | VALUE |
|---|---|
| PH range | 0.00~14.00pH |
| PH Measurement Accuracy | ±0.01pH |
| Resolution | 0.01pH |
| Power Supply | 110或230VAC,50/60Hz |
| Dimensions | 1/4DIN standard body, 96 * 46 * 119mm |
| opening size | 92*45mm |
| Measurement range mV | -1999~1999mV |
| mV resolution | 1mV |
| Measurement Accuracy of mV | ±0.5%F.S |
| Current output range | current output |
| Insulation Voltage/maximum load | 500VDC/550Ω |
| Relay Control Output/Maximum Load | System ON/OFF control/2.5A/230VAC |
| opening size | 92*46mm |
| Shop Accessories | pH electrode, ORP electrode, mounting bracket, sealing box |
JENCO 3621 (set) pH oxidation controller Packing list
Host X1, IP-600-10 (20 meters) X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
