LEICI JPSJ-605F Dissolved Oxygen Meter +/- 0.30mg/L
The LEICI Dissolved Oxygen Meter JPSJ-605F has an automatic temperature compensation function, conforms to GLP specifications, and provides three reading modes. JPSJ-605F is mainly used for tap water source monitoring, aquaculture farms, environmental protection, sewage treatment plants and other parts to determine the dissolved oxygen content.
LeiCi-
LEICI Fluorine ion electrode calibrating solution, suitable for fluorine ion composite electrode
$ 106.00 -
JINGQI WD9201B Portable Water Quality Tester
$ 1502.00 -
SMART SENSOR AR8210 + Pen Dissolving Oxygen Meter (Lithium TV Color Screen)
$ 175.00 -
BANTE S20 Wireless Bluetooth ORP Meter
$ 221.00 -
LEICI DGB-402F Portable residual chlorine total chlorine Tester
$ 560.00










JPSJ-605F dissolved oxygen Tester is mainly used for the determination of dissolved oxygen content or concentration in water by tap water source monitoring, aquaculture farms, environmental protection, sewage treatment plants, beverage industry and scientific research units.
Features
● Adopt color high-definition LCD screen, clear display
● Temperature units are optional: °C and °F.
● Support self-diagnosis, automatic shutdown, power-off protection and factory reset functions
● Support firmware upgrade function, allowing function expansion and personalized requirements
● Support IP54 protection level
● Polarographic dissolved oxygen electrode, electrode holder and dust cover are standard
[Intelligent detection, automatic identification]
● Intelligent endpoint discrimination, support automatic reading, timed reading, timed interval reading, and manual reading
● Support automatic temperature compensation, automatic atmospheric pressure compensation (kPa, mmHg, atm and other units are optional)
● Automatic zero oxygen calibration and full calibration
● Support manual salinity compensation
[Data management, information traceability]
● Support data storage (500 sets each), view, delete, transfer and print
● Comply with GLP and realize data traceability
● With RS-232 interface, it supports connecting to a standard RS-232 serial printer, and directly prints the measurement results, and the printing format is optional
● It has a USB interface, which can be connected with a PC through a dedicated communication software to realize data transmission
LeiCi JPSJ-605F Dissolved Oxygen MeterSpecifications
| LIST | VALUE |
|---|---|
| Instrument level | ±0.30mg/L |
| Measurement parameters | Dissolved oxygen concentration, dissolved oxygen saturation, dissolved oxygen current and temperature value |
| DO range | Electronic unit: (0.00~99.99) mg/L Measurement range: (0.00~50.00) mg/L |
| Resolution | 0.01 mg/L |
| Electronic unit error of indication | ±0.10mg/L |
| An indication of instrument error | ±0.30mg/L |
| Response time | ≤ 45s (90% Response at 20 ℃) |
| Salinity compensation error | ≤±2% |
| DO% Measurement range | 0.0~600.0% |
| Resolution | 0.001 |
| Electronic unit error of indication | ±2.0% |
| An indication of instrument error | ±10.0% |
| Measurement range | -10.0~135.0 ℃ |
| Resolution | 0.1 ℃ |
| Electronic unit error of indication | ±0.1 ℃ |
| An indication of instrument error | +/- 0.3 ℃ (0.0 ℃ -60.0 ℃); +/- 1.0 ℃ (Miscellaneous range) |
| Power Supply | DC24V,2.7A |
| Dimensions | 216*190*63mm |
| Weight | 0.95kg |
LeiCi JPSJ-605F Dissolved Oxygen Meter Packing list
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
