ShangGuang XSP-3CA Monocular Microscope
Monocular, four objectives, 1600X, electric light source
ShangGuangLiuChang
XSP-3CA
XSP-3CA biological microscope can be widely used in medical and health institutions, laboratories, agricultural science institutes, research institutes and colleges and universities for biology, bacteriology, pathology observation, teaching, professional research, clinical experiment and routine medical inspection This product is novel in shape and adopts a variety of professional structures and technologies to make the instrument easy to use, safe and reliable.
Completeness
| 1 | Microscope main body: 1 set |
| 2 | Monocular tube : 1 |
| 3 | 10X , 16X plan eyepieces: 1 pair each |
| 4 | 4 ×, 10 ×, 40 × (spring), 100 × (spring, oil) achromatic objective lens: 1 each |
| 5 | Color filter (blue, yellow, green): 1 piece each |
| 6 | Cedar oil: 1 bottle |
| 7 | 6V20W halogen lamp : 2pcs |
| 8 | Random file: 1 set |
ShangGuangLiuChang XSP-3CA MicroscopeSpecifications
| LIST | VALUE |
|---|---|
| Optical inspection system | Optical inspection system |
| Observation method | Eyepiece tube: monocular tube; Optical inspection method: transmitted light illumination |
| Optical inspection method | Transmitted light illumination |
| Eyepiece parameters | Magnification 10x (standard), 16X (standard) |
| Field of view | 18mm、11mm |
| objective magnification | 4X jets 10X jets 40X jets 100X () |
| Objective numerical aperture NA | 0.1,0.25,0.65,1.25 |
| Objective lens working distance | 37.5mm，7.31mm，0.63mm，0.18mm |
| Objective lens converter | Four hole converter |
| stage | Double-layer mobile platform; table size: 120mm * 120mm; moving range: 70mm * 30mm |
| Focusing range | 15, 20mm; fretting grid value 0.002mm |
| Lighting device | Brightfield transmission illumination with variable diaphragm, adjustable brightness, halogen lamp 20W/6V |
ShangGuangLiuChang XSP-3CA Microscope Packing list
Microscope main body: 1; single eyepiece barrel: 1; 10X, 16X flat field eyepiece: 1 pair each; 4 ×, 10 ×, 40 × (spring), 100 × (spring, oil) color difference objective: 1 each; color filter (blue, yellow, green): 1 piece each; cedar oil: 1 bottle; 6V20W halogen lamp: 2 pieces; random file: 1 set
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
