        ShangGuangLiuChang BM-11 Trinocular Simple Polarizing Microscope

        ShangGuang BM-11 Trinocular Simple Polarizing Microscope

        Eyepiece 10X Four objectives, 40X-1600X, simple polarizer swirl/spin, electric light source, adjustable Abbe condenser (optional photography and camera device)

        Brand
        SKU: NB031639
        China ShangGuangLiuChang
        Model
        Get Quote
        VS
        ShangGuangLiuChangLOGO

        ShangGuangLiuChang shop

        Information
        Datasheet
        What else did others buy
        Genuinegoods

        • ShangGuangLiuChang BM-11 Trinocular Simple Polarizing MicroscopeOverview

        • Specifications
        • Comments
        • FAQs
        BM-11
        Trinocular Simple Polarizing Microscope
        • ShangGuang BM-11 Trinocular Simple Polarizing Microscope
        Eyepiece 10X Four objectives, 40X-1600X, simple polarizer swirl/spin, electric light source, adjustable Abbe condenser (optional photography and camera device)

        Introduction

        Trinocular Polarizing Microscope BM-11 adopts a transmission illumination system with stable performance and clear imaging. It is mainly used to observe and identify various transparent crystals, rocks, minerals, medicines and substances with birefringence. It can also be used in textile and chemical fiber industries to inspect textile fibers, and can also be used in geological research units and related universities, scientific research units, factories and other departments for mineral analysis, crystal observation, drug testing and other applications.


        VS

        ShangGuangLiuChang BM-11 Trinocular Simple Polarizing MicroscopeSpecifications

        LIST VALUE
        Flat field eyepiece Wide field flat field eyepiece: WF10X/18 pair, WF16X/11
        Objective for eliminating color difference 4X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (oil, spring)
        Total magnification 40X-1600X
        observation head Hinged binocular tube, 30 ° tilt, 360 ° swirl/spin The pupil spacing can be adjusted by 55-75mm
        Stage: Diameter? 135mm, 360 ° rotating loading circle table, scale value 1 °, vernier value 6 ′;
        Mechanical barrel length: 160mm
        pupil distance 55-75mm
        Collector: 0 ° -90 ° rotating polarizer, which can be removed from the optical path;
        Specimen polarizer: Optical path compensator: λ test plate (first-class red), 1/4 λ test plate, polarizing device located on the light collecting mirror, 360 ° rotatable;
        Lighting: Built-in dimming 6V/20 halogen lamp.

        ShangGuangLiuChang BM-11 Trinocular Simple Polarizing Microscope Packing list

        1 microscope main body, 1 pair each of eyepiece 10X/16X, 1 each of objective lens 4X/10X/40X/100X (oil), color filter: 1 each of blue/green/yellow, 1 halogen lamp 6V/20W (spare), 1 bottle of cedar oil

        [Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
