PUYUN PY-H602 Computer paper Burst Tester
PUYUN PY-H602 computer paper bursting instrument is mainly used for box Cardboard, kraft paper, cardboard, corrugated paper, gray board paper and other paper resistance to fatigue resistance, PY-H602 computer paper bursting instrument spring tension 4.91~ 14.72N, plus 9.81N force, spring compression at least 17mm, test tension configuration using imported tension configuration.
PuYun
PY-H602
-
CHINA NBC-8502B automatic breaking Strength Tester, touch screen breaking machine
$ 1061.00 -
Essence LD - NP-CMP Cardboard Burst Strength Tester, Vertical Touch Screen Version
$ 1061.00 -
YANTE YT-NPY1600Q paper Burst Strength Tester
$ 2286.00 -
CHINA ZY-NP-2 Cardboard Burst Tester
$ 1361.00 -
Taichang TC-NPD5600Q Pneumatic Cardboard Burst Tester 250kPa~ 5600kPa
$ 1311.00
Introduction
Paperboard fiber folding resistance Tester, also known as fatigue folding resistance testing machine, is used for the detection of the number of folds and fold resistance of paper, mainly used for cardboard, kraft paper, cardboard, corrugated paper, gray board paper and other paper bending fatigue resistance, suitable for paper production enterprises, cardboard carton manufacturers, quality supervision bureaus, scientific research institutions, etc.
Standard basis
GBT2679.5 Determination of fold resistance of paper and cardboard (MIT fold resistance method), ISO 5626 paper Determination of fold resistance
PuYun PY-H602 Computer paper Burst TesterSpecifications
| LIST | VALUE |
|---|---|
| Measurement range | 0~99999 times |
| folding angle | Material yield bending angle is steplessly adjustable from 0 ° to 142 ° |
| folding speed | The bending speed is adjustable from 10 times/min to 2000 times/min |
| Spring tension | 4.91~ 14.72N, plus a force of 9.81N, the spring compresses at least 17mm. |
| Test tension configuration | Adopting imported tension configuration, the tension coefficient is twice higher than that of China brand Stability. |
| Folding chuck | The tension change caused by swirl/spin eccentricity is not more than 0.343N. |
| The width of the folding head is | 19±1mm |
| crease radius | 0.38±0.02mm |
| Specimen length | ≥140mm |
| Crease temperature change | ≤1℃ ，AFTER 4H |
| Collet distance | 9.5mm |
| Lower clamp clamping method | Cylinder knurled knob for easier clamping |
| The distance between the cracks of the folding mouth | 0.25Mm/0.5mm/0.75mm/1.00mm (according to requirements) |
| Display | 5.in LCD display, real-time display of test data |
| printout | modular integrated thermal printer |
| Operating Environment | Temperature (0~35) ℃, Humidity < 85% |
| Power supply Voltage | AC220V，50Hz |
PuYun PY-H602 Computer paper Burst Tester Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
