JingTian LVDV-1 + L0 Digital Rotational Viscometer

JINGTIAN LVDV-1 digital Rotational Viscometer viscosity Measurement Instrument with L0 rotor

JINGTIAN LVDV-1 digital display Rotational Viscometer measurement accuracy ± 1%, reproducibility ± 0.5%, with L0 rotor, LVDV-1 digital display Rotational Viscometer can display Viscosity, shear rate, shear stress, speed, temperature, percentile torque, rotor number.

Brand

SKU: NB035842

JingTian

Model

LVDV-1 + L0

Get Quote

JingTian shopSE

Information

Datasheet Video Catalog Manual

What else did others buy

NIRUN NTV-P2RV touch screen Rotational Viscometer Rotor Viscosity-Meter 40M mPa · s

$ 3938.00
FANGRUI HA-SSR Digital Rotational Viscometer for small samples

$ 1027.00
FANGRUIs ULR-Plus Ultra Low Viscosity Adapter, Enhanced, with Recycling Jacket, Optional

$ 340.00
NIRUN NTV-CAP2 cone-plate viscometer Rotation speed 900rpm/750rpm/400rpm

$ 7341.00
Ander NDJ-79 Pointer Viscometer Viscosity Range 2~ 1000000mPa·s

$ 568.00

Genuinegoods

JingTian LVDV-1 + L0 Digital Rotational ViscometerOverview
Specifications
Comments
FAQs

LVDV-1 + L0

Digital Rotational Viscometer

Introduction

The LCD of Shanghai JINGTIAN LVDV-1 digital display rotary viscometer can display viscosity, shear rate, shear stress, rotational speed, temperature, percentile torque, rotor number and the maximum measurable value of the selected rotor at the current rotational speed. Viscosity value etc. It is a digital display rotary viscometer with a measuring range of 12 to 6,000,000 mPa·s.

Details of JINGTIAN LVDV-1+L0 Digital Display Rotary Viscometer 1

Introduction

Accurately measure ultra-low viscosity samples

Sample volume only needs 25~30mL

It can measure lower viscosity and be used with different types of viscometers

Details of JINGTIAN LVDV-1+L0 Digital Display Rotary Viscometer 2

JingTian LVDV-1 + L0 Digital Rotational ViscometerSpecifications

LIST	VALUE
Measuring range	0.6~6000000mPa·s
Rotor Specifications	L0#、L1#、L2#、L3#、L4#
Reproducibility	±0.5%F.S
Measurement Accuracy	±1%F.S
Power	Dedicated power adapter (input 100~240V 50~60Hz)
Rotor speed	0.1~99.9rpm
Display information	Viscosity, rotational speed, temperature, percentile torque, rotor number and the maximum Viscosity value that can be measured at the current rotational speed of the selected rotor, etc
Speed control method	CVT

JingTian LVDV-1 + L0 Digital Rotational Viscometer Packing list

Host X1, protection frame X1, rotor X1 (sleeve), L0 rotor, base and horizontal adjustment bolt X1, lifting frame and lifting mechanism X1, special power adapter X1, wrench X1, RTD temperature probe X1, RS232 standard output interface X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

RVDV-1 Can this Viscometer measure the viscosity of 3.5-5 mPa.s?

[A]

Use the LVDV-1 model with the L0 rotor.

[Q]

Also, is this model a coaxial cylinder rotational viscometer? I think how is the rotor Viscometer?

[A]

The coaxial cylinder rotational viscometer is also a kind of rotor rotational viscometer. The conventional rotor rotational viscometer, we call it "coaxial single cylinder rotational viscometer", which is a rotor extending into the material to directly test the viscosity. The coaxial cylinder Viscometer adds a set of Accessories on the basis of the standard standard Viscometer, which are usually a small number of sample adapters or ultra-low viscosity adapters, so this set is called the coaxial cylinder rotational viscometer, which is actually a coaxial binocular rotational viscometer.

[Q]

Does this Viscometer meet the SY/T0522 standard?

[A]

This Viscometer is suitable for SY/T0522. Please consult customer service for detailed application definition.

[Q]

I haven't done any testing before, and I don't know how to do it. How to choose a Viscometer?

[A]

It is easy to make the results of the viscosity test. After the measurement, he said that it is different from others, so it is wrangling. If the next home has viscosity requirements for his products, ask the next home for detection methods. If the purchase inspection, ask the previous home for Measurement conditions and methods. There are many viscosity measurement methods, and the measurement results cannot be converted.
