TENLIN DC-4020 Vertical Low Temperature Circulating Bath - 40 ℃/ +/- 0.05 ℃ 20L

Features

● New self-developed temperature control technology, equipped with high-standard PT100 and all imported electronic components.

● The software system can correct the error between the displayed temperature and the actual temperature, so that the displayed temperature value is accurate.

● Equipped with large-screen liquid crystal display as standard, multiple data can be seen at a glance, and the resolution of temperature display is up to 0.01℃.

● With over-temperature protection, over-temperature beep alarm, over-temperature alarm temperature can be set, and the load can be automatically cut off when over-temperature.

● With timing function, the total working time of the equipment can be set, and the load will be cut off automatically when the time comes.

● Hidden cooling coil design ensures a larger space in the tank.

● Intelligent software has strong temperature stability, PID can automatically adjust the appropriate parameters according to different media, and special users can manually readjust the parameters.

● Use the software to digitally lock the setting values ​​of the control system to avoid misoperation by irrelevant personnel and ensure that the data during the experiment is correct.

● Effective full-enclosed compressor refrigeration, fast cooling speed, with multiple protections such as overheating and overcurrent.

● The internal and external circulation function is equipped as standard, and the outer diameter of the external circulation inlet and outlet is a round pipe with an outer diameter of 10mm, which meets the different needs of users in multiple scenarios.

● Support non-standard customization.

Optional

Liquid level protection system --- When the liquid level exceeds the limit, the load will be stopped forcibly to protect the user's experiment.

RS485 communication interface--connect to a host computer such as a computer, and the host computer software controls the device and checks the data.

Multi-point correction function-can correct multiple temperature points at the same time, avoiding the temperature difference caused by the linear error of the sensor.

External PT100 - can realize the precise temperature control of the external circulation.

Bracket--Satisfied that different containers are placed in the tank to avoid being submerged in constant temperature liquid.

external structure

Figure 1: Outline structure of DC constant temperature bath

Figure 2: DC thermostatic bath control panel

Model parameters

host X1, cover X1, manual X1, certificate X1, warranty card X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
