HONGKE DHG-9101-2SA Electric thermostatic Forced Air Drying Oven thermostatic oven
HONGKE DHG-9101-2SA electric thermostatic Forced Air Drying Oven Temperature range RT+ + 10~300 ℃, Temperature fluctuation +/- 1 ℃, Interior size 450 * 550 * 550mm, DHG-9101-2SA electric thermostatic Forced Air Drying Oven has self-tuning function Setting and measured two temperatures can be displayed at the same time.
HongKe-
HUITAI DHG-9260A Blast drying oven Electric heating oven 260L
$ 763.00 -
SANFA DHG-9202-2 Electric thermostatic Drying Oven 300 ℃/140L
$ 433.00 -
HUITAI DZF-6050 Vacuum Oven volume 50L with intelligent program controller
$ 860.00 -
YIHENG BPG-9760AH high temperature Forced Air Drying Oven volume 760L temperature control up to 400 ℃
$ 5703.00 -
HUITAI DHG-9245A Blast drying oven Industrial oven 220L temperature control RT + 10~ 300 ℃
$ 732.00
Application
This product is equipment used for drying, baking, melting wax, and sterilizing . It is suitable for scientific research and production in the fields of factory production experiments, medical research, health and epidemic prevention, drug inspection, environmental protection, and rural science.
Model Selection
| model | Power consumption | studio size |
| DHG-9030 | 500 | 350*350*350 |
| DHG-9101-0S | 500 | 350*350*350 |
| DHG-9030A | 500 | 350*350*350 |
| DHG-9101-0SA | 500 | 350*350*350 |
| DHG-9070 | 1000 | 450*350*450 |
| DHG-9101-1S | 1000 | 450*350*450 |
| DHG-9070A | 1000 | 450*350*450 |
| DHG-9101-1SA | 1000 | 450*350*450 |
| DHG-9140 | 1500 | 450*550*550 |
| DHG-9101-2S | 1500 | 450*550*550 |
| DHG-9140A | 1500 | 450*550*550 |
| DHG-9101-2SA | 1500 | 450*550*550 |
| DHG-9240 | 2000 | 500*600*750 |
| DHG-9101-3S | 2000 | 500*600*750 |
| DHG-9240A | 2000 | 500*600*750 |
| DHG-9101-3SA | 2000 | 500*600*750 |
| DHG-9624 | 4000 | 800*800*1000 |
| DHG-9101-4S | 4000 | 800*800*1000 |
| DHG-9624A | 4000 | 800*800*1000 |
| DHG-9101-4SA | 4000 | 800*800*1000 |
| A: stainless steel liner, S: intelligent digital display temperature controller | ||
| Unit: W, mm | ||
| Other parameters | ||
| Voltage | 220V 50Hz | |
| Temperature control range | RT+10~300℃ | |
| temperature fluctuation | ±1℃ | |
Precautions
1. The shell of the drying box needs to be effectively grounded to ensure safe use.
2. The drying box should be placed in a room with good ventilation conditions, and no flammable and explosive materials can be placed around it or in the box.
3. Do not overcrowd the items in the box, and leave space.
4. The inside and outside of the box should be kept clean. If it is not used for a long time, it should be covered with a plastic dust cover and placed in a dry room.
HongKe DHG-9101-2SA Electric thermostatic Drying OvenSpecifications
| LIST | VALUE |
|---|---|
| Power supply Voltage | 220V 50Hz |
| Power consumption | 1500W |
| Temperature range | RT+10~300℃ |
| Temperature Fluctuation | ±1℃ |
| Interior size | 450*550*550mm |
| Dimension | 720*780*750mm |
| shelf (std.) | 2pcs |
| Packaging Dimensions | 810*880*860mm |
| Volume | 0.6m³ |
| Net Weight | 65KG |
| Gross Weight | 83KG |
HongKe DHG-9101-2SA Electric thermostatic Drying Oven Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
