        Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane Detector

        Skyeaglee SK/MIC-600-CH4-Y Combustible CH4 Gas Detector Infrared NDIR

        Detection gas flammable CH4, detection range 0-100% vol, resolution 0.1% vol, detection principle infrared NDIR, Operating Mode fixed continuous work, diffusion type, pipeline type, flow, pump suction optional.

        Brand
        SKU: NB036976
        China Skyeaglee
        Get Quote
        VS
        SkyeagleeLOGO

        Skyeaglee shopSE

        Information
        Datasheet Video Catalog Manual
        What else did others buy
        Genuinegoods

        • Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane DetectorOverview

        • Specifications
        • Comments
        • FAQs
        SK/MIC-600-CH4-Y (Infrared NDIR)
        Online methane Detector
        • Skyeaglee SK/MIC-600-CH4-Y Combustible CH4 Gas Detector Infrared NDIR
        • Skyeaglee SK/MIC-600-CH4-Y Combustible CH4 Gas Detector Infrared NDIR Figure 1
        • Skyeaglee SK/MIC-600-CH4-Y Combustible CH4 Gas Detector Infrared NDIR Figure 2
        Detection gas flammable CH4, detection range 0-100% vol, resolution 0.1% vol, detection principle infrared NDIR, Operating Mode fixed continuous work, diffusion type, pipeline type, flow, pump suction optional.

        SK/MIC-600 online gas concentration Detector is a modular design, with intelligent sensor detection technology,Flameproof (D) structure and fixed installation of flammable gas monitor. The standard configuration is a dot matrix LCD display, three-wire 4~20mA modeFit and RS485 digital signal output, optional configuration as programmable switching output and other modules, according to user needs to provide customized products, but also support output signal fine-tuning and other functions, convenient system networking and maintenance.

        ● On-line gas concentration Detector

        ● Automatic temperature compensation, zero point, full-scale drift compensation

        ● Automatic protection function against high-concentration gas impact

        ● Full software calibration function, users can also calibrate by themselves, with 3 buttons to achieve, easy to operate

        ● 2-wire 4-20mA output

        Place of application

        Paint room, incineration plant, scientific research, production workshop, company, environmental monitoring, school scientific research, building construction, fire alarm, sewageProcessing, Industrial Gas Process ControlPetroleum & Petrochemical, Chemical Plants, Smelters, Iron & Steel Plants, Coal Plants, Thermal Power Plants, Boiler Rooms, Waste Treatment Plants,Tunnel construction, oil pipelines, gas stations, underground gas pipeline maintenance, indoor air quality testing, hazardous place safety protection equipment monitoring, etc.(The data is for reference only; please also make the corresponding selection according to your actual Operating Conditions) The data shows: the usual temperature range is -20°C ~ +50°C, humidity10%RH ~ 90%RH no condensation, the absolute pressure is 106KPa±20KPa, where ±20KPa is the relative pressure, relative to the atmospheric pressureForce.

        Structural diagram

        Details of the SK/MIC-600-CH4-Y (Infrared NDIR) On-line Methane Detector Figure 1

        On-line gas concentration Detector diagram Electrical wiring definition diagram (Figure 2: The main unit represents the control system such as C PLC and computer.)

        Details of the SK/MIC-600-CH4-Y (Infrared NDIR) On-line Methane Detector Figure 2

        Figure 1

        Details of the SK/MIC-600-CH4-Y (Infrared NDIR) On-line Methane Detector Figure 3

        Figure 2


        Online gas concentration Detector debugging calibration diagram:

        Details of the SK/MIC-600-CH4-Y (Infrared NDIR) On-line Methane Detector Figure 4

        Series optional

        Detection of gasesRangeMaximum allowed
                    Error value        		Minimum readingWhen responding
                    T90
        Combustible (EX )0-100%LEL＜±3%(F.S)0.1%LEL≤10 seconds
        Combustible (EX )0-100%Vol＜±3%(F.S)0.1%Vol≤10 seconds
        Methane (CH4 )0-100%LEL＜±3%(F.S)0.1%LEL≤10 seconds
        Methane (CH4 )0-100%Vol＜±3%(F.S)0.1%Vol≤10 seconds
        Oxygen (O2 )0-30%Vol＜±3%(F.S)0.01%Vol≤10 seconds
        Oxygen (O2 )0-100%Vol＜±3%(F.S)0.01%Vol≤10 seconds
        Oxygen (O2 )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Nitrogen (N2 )0-100%Vol＜±3%(F.S)0.01%Vol≤10 seconds
        Carbon Monoxide (CO)0-100ppm＜±3%(F.S)0.1ppm≤25 seconds
        Carbon Monoxide (CO)0-1000ppm＜±3%(F.S)0.1ppm≤25 seconds
        Carbon Monoxide (CO)0-2000ppm＜±3%(F.S)0.1ppm≤25 seconds
        Carbon Monoxide (CO)0-20000ppm＜±3%(F.S)1ppm≤25 seconds
        Carbon Monoxide (CO)0-100000ppm＜±3%(F.S)1ppm≤25 seconds
        Carbon dioxide ( CO2 )0-500ppm＜±3%(F.S)1ppm≤20 seconds
        Carbon dioxide ( CO2 )0-2000ppm＜±3%(F.S)1ppm≤20 seconds
        Carbon dioxide ( CO2 )0-5000ppm＜±3%(F.S)1ppm≤20 seconds
        Carbon dioxide ( CO2 )0-50000ppm＜±3%(F.S)1ppm≤30 seconds
        Carbon dioxide ( CO2 )0-20%Vol＜±3%(F.S)0.01%Vol≤30 seconds
        Carbon dioxide ( CO2 )0-100%Vol＜±3%(F.S)0.01%Vol≤30 seconds
        Formaldehyde (CH2O )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Formaldehyde (CH2O )0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Formaldehyde (CH2O )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Formaldehyde (CH2O )0-5000ppm＜±3%(F.S)1ppm≤50 seconds
        Ozone (O.)3 )0-1ppm＜±3%(F.S)0.001ppm≤20 seconds
        Ozone (O.)3 )0-5ppm＜±3%(F.S)0.001ppm≤20 seconds
        Ozone (O.)3 )0-50ppm＜±3%(F.S)0.01ppm≤20 seconds
        Ozone (O.)3 )0-100ppm＜±3%(F.S)0.01ppm≤20 seconds
        Ozone (O.)3 )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Ozone (O.)3 )0-30000ppm＜±3%(F.S)1ppm≤30 seconds
        Ozone (O.)3 )0-20mg/L＜±3%(F.S)0.01mg/L≤30 seconds
        Ozone water (O3 )0-20mg/L＜±3%(F.S)0.01mg/L≤30 seconds
        Hydrogen sulfide (H2S )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Hydrogen sulfide (H2S )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen sulfide (H2S )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen sulfide (H2S )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Hydrogen sulfide (H2S )0-10000ppm＜±3%(F.S)1ppm≤45 seconds
        Sulfur dioxide (SO)2 )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Sulfur dioxide (SO)2 )0-20ppm＜±3%(F.S)0.01ppm≤30 seconds
        Sulfur dioxide (SO)2 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Sulfur dioxide (SO)2 )0-500ppm＜±3%(F.S)0.1ppm≤30 seconds
        Sulfur dioxide (SO)2 )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Sulfur dioxide (SO)2 )0-10000ppm＜±3%(F.S)1ppm≤30 seconds
        Nitric Oxide (NO)0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Nitric Oxide (NO)0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Nitric Oxide (NO)0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Nitric Oxide (NO)0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Nitrogen dioxide (NO2 )0-10ppm＜±3%(F.S)0.001ppm≤25 seconds
        Nitrogen dioxide (NO2 )0-100ppm＜±3%(F.S)0.01ppm≤25 seconds
        Nitrogen dioxide (NO2 )0-1000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Nitrogen dioxide (NO2 )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Nitrogen oxides (NO.)X )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Nitrogen oxides (NO.)X )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Nitrogen oxides (NO.)X )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Nitrogen oxides (NO.)X )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Chlorine (CL2 )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Chlorine (CL2 )0-20ppm＜±3%(F.S)0.01ppm≤30 seconds
        Chlorine (CL2 )0-200ppm＜±3%(F.S)0.1ppm≤30 seconds
        Chlorine (CL2 )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Ammonia (NH3 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ammonia (NH3 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ammonia (NH3 )0-1000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Ammonia (NH3 )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Ammonia (NH3 )0-100%LEL＜±3%(F.S)0.1%LEL≤10 seconds
        Hydrogen ( H2 )0-100%LEL＜±3%(F.S)0.1%LEL≤10 seconds
        Hydrogen ( H2 )0-1000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Hydrogen ( H2 )0-20000ppm＜±3%(F.S)1ppm≤30 seconds
        Hydrogen ( H2 )0-40000ppm＜±3%(F.S)1ppm≤30 seconds
        Hydrogen ( H2 )0-100%Vol＜±3%(F.S)0.01%Vol≤20 seconds
        Helium ( He )0-100%Vol＜±3%(F.S)0.01%Vol≤20 seconds
        Argon ( Ar )0-100%Vol＜±3%(F.S)0.01%Vol≤20 seconds
        Xenon ( Xe )0-100%Vol＜±3%(F.S)0.01%Vol≤20 seconds
        Hydrogen cyanide (HCN)0-30ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen cyanide (HCN)0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen chloride (HCL)0-20ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen chloride (HCL)0-200ppm＜±3%(F.S)0.1ppm≤30 seconds
        Phosphine (PH3 )0-5 ppm＜±3%(F.S)0.001ppm≤30 seconds
        Phosphine (PH3 )0-25 ppm＜±3%(F.S)0.01ppm≤30 seconds
        Phosphine (PH3 )0-2000 ppm＜±3%(F.S)1ppm≤30 seconds
        Chlorine dioxide (CLO2 )0-1ppm＜±3%(F.S)0.001ppm≤30 seconds
        Chlorine dioxide (CLO2 )0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Chlorine dioxide (CLO2 )0-200ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethylene Oxide (ETO)0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethylene Oxide (ETO)0-1000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Ethylene Oxide (ETO)0-100%LEL＜±3%(F.S)1%LEL≤30 seconds
        Phosgene (COCL2 )0-1ppm＜±3%(F.S)0.001ppm≤20 seconds
        Phosgene (COCL2 )0-50ppm＜±3%(F.S)0.01ppm≤20 seconds
        Silanes (SiH4 )0-1ppm＜±3%(F.S)0.001ppm≤30 seconds
        Silanes (SiH4 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Fluorine (F2 )0-1ppm＜±3%(F.S)0.001ppm≤30 seconds
        Fluorine (F2 )0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Fluorine (F2 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen fluoride (HF)0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen fluoride (HF)0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen bromide (HBr)0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethylborane (B2H6 )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Hydrogen arsenide (AsH3 )0-1ppm＜±3%(F.S)0.001ppm≤30 seconds
        Hydrogen arsenide (AsH3 )0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen arsenide (AsH3 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Germanane (GeH4 )0-2ppm＜±3%(F.S)0.001ppm≤30 seconds
        Germanane (GeH4 )0-20ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrazine, hydrazine ( N2H4 )0-1ppm＜±3%(F.S)0.001ppm≤30 seconds
        Hydrazine, hydrazine ( N2H4 )0-300ppm＜±3%(F.S)0.1ppm≤30 seconds
        Tetrahydrothiophene (THT)0-100mg/m3＜±3%(F.S)0.01 mg/m3≤60 seconds
        Bromine gas (Br2 )0-10ppm＜±3%(F.S)0.001ppm≤30 seconds
        Bromine gas (Br2 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Bromine gas (Br2 )0-2000ppm＜±3%(F.S)1ppm≤30 seconds
        Acetylene (C2H2 )0-100%LEL＜±3%(F.S)0.1%LEL≤30 seconds
        Acetylene (C2H2 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Acetylene (C2H2 )0-1000ppm＜±3%(F.S)0.1ppm≤30 seconds
        Ethylene (C2H4 )0-100%LEL＜±3%(F.S)0.1%LEL≤30 seconds
        Ethylene (C2H4 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethylene (C2H4 )0-2000ppm＜±3%(F.S)0.1ppm≤30 seconds
        acetaldehyde0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethanol (C2H6O )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Ethanol (C2H6O )0-2000ppm＜±3%(F.S)1ppm≤30 seconds
        Methanol (CH6O )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Methanol (CH6O )0-2000ppm＜±3%(F.S)1ppm≤30 seconds
        Carbon disulfide (CS2 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Carbon disulfide (CS2 )0-5000ppm＜±3%(F.S)0.01ppm≤30 seconds
        Acrylonitrile (C3H3N )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Acrylonitrile (C3H3N )0-2000ppm＜±3%(F.S)1ppm≤30 seconds
        Methylamine (CH)5N )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Dian Qi ( I2 )0-50ppm＜±3%(F.S)0.01ppm≤30 seconds
        Styrene (C8H8 )0-200ppm＜±3%(F.S)0.1ppm≤30 seconds
        Styrene (C8H8 )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Vinyl chloride (C2H3CL )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Trichloroethylene (C2HCL3 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Perchloroethylene (C2CL4 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Laughing gas (N2O )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Nitrogen trifluoride (NF3 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Hydrogen peroxide (H2O2 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Methyl bromide (CH3Br )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Methyl bromide (CH3Br )0-30000ppm＜±3%(F.S)1ppm≤30 seconds
        Methyl bromide (CH3Br )0-200g/m3＜±3%(F.S)0.1g/m3≤30 seconds
        Sulfuryl fluoride (SO2F2 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Sulfuryl fluoride (SO2F2 )0-5000ppm＜±3%(F.S)1ppm≤30 seconds
        Sulfuryl fluoride (SO2F2 )0-10000ppm＜±3%(F.S)1ppm≤30 seconds
        Benzene (C6H6 )0-10ppm＜±3%(F.S)0.01ppm≤30 seconds
        Benzene (C6H6 )0-100ppm＜±3%(F.S)0.01ppm≤30 seconds
        Benzene (C6H6 )0-2000ppm＜±3%(F.S)1ppm≤30 seconds


        VS

        Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane DetectorSpecifications

        LIST VALUE
        Detection gas Combustible CH4
        range 0 ~ 100% vol
        Resolution 0.1% vol
        Sensors principle Infrared NDIR
        Operating Mode Fixed type continuous work, diffusion type, pipeline type, when circulating, pump suction type is optional.
        Detection Accuracy ≦3%（F.S）
        Response time ≦30S
        output signal Current signal output 4-20MA
        Alarm method 2 passive node signal output, alarm point can be set.
        Operating temperature -20~50℃
        Relative Humidity ≦90%RH
        Working Voltage DC12~30V
        Sensors Life 2 years
        Explosion-proof method Probe Transmitters and Sensors are flameproof
        Explosion-proof sign ExdIICT6
        Connection cable Three-core cable (single Wire diameter ≥ 1.5mm); Shielding cable is recommended
        Connection distance ≦1000 m
        Protection class IP66
        Dimensions 183*143*107mm
        Weight 1.5kg

        Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane Detector Packing list

        Host X1, sound and light alarm light X1, sealing soft glue X1, detector manual X1, certificate X1

        [Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

        FAQ

        [Q]
        Is the price listed on the website the final cost for overseas purchases?
        [A]
        No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
        [Q]
        What is the specific process for purchasing the product?
        [A]
        First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
        [Q]
        What should I do if the instrument I purchase needs repair?
        [A]
        After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
        +Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane Detector Big data
          +Skyeaglee SK/MIC-600-CH4-Y (Infrared NDIR) Online methane DetectorStandard
          +Navigation
          Skyeaglee
          Skyeaglee SK/MIC-600-CH4-Y Combustible CH4 Gas Detector Infrared NDIR
          Service
          Order Guide
          Payment & Shipping
          After-sales
          Cooperation
          About Us
          Focus on online sales of Lab Testing Instruments

          CopyRight © NBchao.Com 2012-2024, All Rights Reserved.
