Skyeaglee SK/MIC-800-H2-Y/100% Portable hydrogen Detector

SK/MIC-800-H2-Y/100% portable hydrogen Detector, hydrogen H2 thermal conductivity 100% vol

Equipped with HLP Sensors, hydrogen H2, range 0~100% vol, resolution 0.1% vol, detection principle thermal conductivity, Operating Mode pump suction, sampling accuracy ≤ 3% F.S, repeability 3% F.S

Brand

SKU: NB037109

Skyeaglee

Model

SK/MIC-800-H2-Y/100%

Get Quote

Skyeaglee shopSE

Information

Datasheet Video Manual

What else did others buy

HONEYEAGLE HNAG1000-NO2 Fixed Nitrogen Dioxide Detector 0-250PPM

$ 509.00
Empaer AATL-CO2 (4G) Pathfinder Series Stationary CO2 Detector

$ 989.00
GUOYUGRA GY/VGD-200-SiH4-G (0-10ppm) Silane Detector

$ 568.00
SuJie Y09-01D Portable dust particle counter 2.83L/min

$ 2350.00
HUIRUIPU HRP-K6000-8 Eight-way gas alarm controller, button model

$ 204.00

Genuinegoods

Skyeaglee SK/MIC-800-H2-Y/100% Portable hydrogen DetectorOverview
Specifications
Comments
FAQs

SK/MIC-800-H2-Y/100%

Portable hydrogen Detector

Equipped with HLP Sensors, hydrogen H2, range 0~100% vol, resolution 0.1% vol, detection principle thermal conductivity, Operating Mode pump suction, sampling accuracy ≤ 3% F.S, repeability 3% F.S

SK/MIC-800 series handheld Gas Detectors use EFM ultra-low power consumption 32-bit ARM, the sensor adopts a professional imported catalytic combustion sensor, and the sensor part uses a two-stage high-precision low-temperature drift amplifier and a highly stable power supply. The processing circuit ensures that the instrument detects fast, accurate, stable and repeatable, making the instrument the most professional and stable Gas Detector and leak Detector in the world. The instrument adopts a large full-color 3.5-inch TFT screen, supports Chinese and English, and graphic menu operation, which is easy for users to operate.

Features

Adopt imported high-precision sensors;

High-precision low-temperature drift amplifiers and stable power processing circuits are used;

TFT3.5-inch full-color display, graphical menu, Chinese and English display, providing real-time detection trend analysis chart;

Data storage function, can store 200,000 sets of data, and the storage interval is adjustable;

USB interface for high-speed data transmission, print data can be downloaded;

Built-in long-life imported micro sampling pump, adjust the cleaning air circuit through gear;

Comply with explosion-proof certification, explosion-proof grade: Exia Ⅱ CT4

Shell two-color mold: non-slip, waterproof, dustproof, explosion-proof

Functions

Pump suction detection method: divided into three gears, low-grade, medium-grade and high-grade

Monitor the concentration of gases in the environment or confined spaces and alarm

With self-calibration function, zero-point calibration function, multi-point calibration function

With temperature and pressure compensation, it can well realize the compensation of gas concentration in different temperature and pressure environments

One-click factory reset function can avoid the trouble of misoperation

Gas concentration unit LEL,% LEL can quickly switch the display;

With self-programming function, alarm parameters, STEL and TWA function parameters can be set

There are two detection modes: normal detection mode and patrol mode;

The detection gas circuit has an automatic cleaning function, which automatically prompts the failure of the instrument, the expiration and failure functions of the sensor calibration, and the real-time display characteristics of the detected maximum value, STEL, TWA and concentration value

Dimensions

SK/MIC-800 Portable Formaldehyde Detector1

Series

Gas	Range	Max. error	Min. reading	Response timeT90
EX	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10s
EX	0-100%Vol	＜±3%(F.S)	0.1%Vol	≤10s
CH4	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10s
CH4	0-100%Vol	＜±3%(F.S)	0.1%Vol	≤10s
O2	0-30%Vol	＜±3%(F.S)	0.01%Vol	≤10s
	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤10s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
N2	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤10s
CO	0-100ppm	＜±3%(F.S)	0.1ppm	≤25s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤25s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤25s
	0-20000ppm	＜±3%(F.S)	1ppm	≤25s
	0-100000ppm	＜±3%(F.S)	1ppm	≤25s
CO2	0-500ppm	＜±3%(F.S)	1ppm	≤20s
	0-2000ppm	＜±3%(F.S)	1ppm	≤20s
	0-5000ppm	＜±3%(F.S)	1ppm	≤20s
	0-50000ppm	＜±3%(F.S)	1ppm	≤30s
	0-20%Vol	＜±3%(F.S)	0.01%Vol	≤30s
	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤30s
CH2O	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤50s
O3	0-1ppm	＜±3%(F.S)	0.001ppm	≤20s
	0-5ppm	＜±3%(F.S)	0.001ppm	≤20s
	0-50ppm	＜±3%(F.S)	0.01ppm	≤20s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤20s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-30000ppm	＜±3%(F.S)	1ppm	≤30s
	0-20mg/L	＜±3%(F.S)	0.01mg/L	≤30s
H2S	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-10000ppm	＜±3%(F.S)	1ppm	≤45s
SO2	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-20ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-500ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-10000ppm	＜±3%(F.S)	1ppm	≤30s
NO	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
NO2	0-10ppm	＜±3%(F.S)	0.001ppm	≤25s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤25s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
NOX	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
CL2	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-20ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-200ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
NH3	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10s
H2	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤10s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-20000ppm	＜±3%(F.S)	1ppm	≤30s
	0-40000ppm	＜±3%(F.S)	1ppm	≤30s
	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20s
He	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20s
Ar	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20s
Xe	0-100%Vol	＜±3%(F.S)	0.01%Vol	≤20s
HCN	0-30ppm	＜±3%(F.S)	0.01ppm	≤30s
HCN	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
HCL	0-20ppm	＜±3%(F.S)	0.01ppm	≤30s
HCL	0-200ppm	＜±3%(F.S)	0.1ppm	≤30s
PH3	0-5ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-25ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	1ppm	≤30s
CLO2	0-1ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-200ppm	＜±3%(F.S)	0.01ppm	≤30s
ETO	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30s
	0-100%LEL	＜±3%(F.S)	1%LEL	≤30s
COCL2	0-1ppm	＜±3%(F.S)	0.001ppm	≤20s
COCL2	0-50ppm	＜±3%(F.S)	0.01ppm	≤20s
SiH4	0-1ppm	＜±3%(F.S)	0.001ppm	≤30s
SiH4	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
F2	0-1ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
HF	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
HF	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
HBr	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
B2H6	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
AsH3	0-1ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
GeH4	0-2ppm	＜±3%(F.S)	0.001ppm	≤30s
GeH4	0-20ppm	＜±3%(F.S)	0.01ppm	≤30s
N2H4	0-1ppm	＜±3%(F.S)	0.001ppm	≤30s
N2H4	0-300ppm	＜±3%(F.S)	0.1ppm	≤30s
THT	0-100mg/m3	＜±3%(F.S)	0.01mg/m3	≤60s
Br2	0-10ppm	＜±3%(F.S)	0.001ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	1ppm	≤30s
C2H2	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-1000ppm	＜±3%(F.S)	0.1ppm	≤30s
C2H4	0-100%LEL	＜±3%(F.S)	0.1%LEL	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	0.1ppm	≤30s
CH3CHO	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
C2H6O	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
C2H6O	0-2000ppm	＜±3%(F.S)	1ppm	≤30s
CH6O	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
CH6O	0-2000ppm	＜±3%(F.S)	1ppm	≤30s
CS2	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
CS2	0-5000ppm	＜±3%(F.S)	0.01ppm	≤30s
C3H3N	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
C3H3N	0-2000ppm	＜±3%(F.S)	1ppm	≤30s
CH5N	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
I2	0-50ppm	＜±3%(F.S)	0.01ppm	≤30s
C8H8	0-200ppm	＜±3%(F.S)	0.1ppm	≤30s
C8H8	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
C2H3CL	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
C2HCL3	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
C2CL4	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
N2O	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
NF3	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
H2O2	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
CH3Br	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-30000ppm	＜±3%(F.S)	1ppm	≤30s
	0-200g/m3	＜±3%(F.S)	0.1g/m3	≤30s
SO2F2	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-5000ppm	＜±3%(F.S)	1ppm	≤30s
	0-10000ppm	＜±3%(F.S)	1ppm	≤30s
C6H6	0-10ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-100ppm	＜±3%(F.S)	0.01ppm	≤30s
	0-2000ppm	＜±3%(F.S)	1ppm	≤30s

Skyeaglee SK/MIC-800-H2-Y/100% Portable hydrogen DetectorSpecifications

LIST	VALUE
Detection gas	Hydrogen H2
range	0 ~ 100% vol
Resolution	0.1% vol
Sensors principle	thermal conductivity
Operating Mode	Pump suction
Sampling Accuracy	≦3%F.S
Sexual repeability	3%F.S
Long term drift	≤±3% (F.S/年)
Response time	≤10S
Warm-up period	30S
Operating Current	≤50mA
data storage	USB data collection, 300,000 group information storage
service life	3 years
Operating Pressure	86kpa-106kpa
Shell material	Anti-corrosion plastic, aluminum alloy
Operating temperature	-30~50℃
Environment humidity	10~95% RH non-condensing
Storage temperature	-30~70℃
Dimensions	228 * 84 * 50.5mm excluding sampling tube
Weight	1.5kg
Explosion-proof sign	Exia II CT4

Skyeaglee SK/MIC-800-H2-Y/100% Portable hydrogen Detector Packing list

Portable detector X1, sampling tube X1, certificate X1, detector manual X1, charger X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

Can your H2 detector detect H2 in environments from 0 to 10% O2?

[A]

Sure
