        Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine Detector

        SK/MIC-800-F2-Y/10000 Portable fluorine Gas Detector, fluorine gas F2 electrochemistry 10000ppm

        Detection gas fluorine F2, range 0~10000ppm, resolution 0.1ppm, detection principle electrochemistry, Operating Mode pump suction, sampling accuracy ≤ 3% F.S, repeability 3% F.S

        Brand
        SKU: NB037150
        China Skyeaglee
        Get Quote
        VS
        SkyeagleeLOGO

        Skyeaglee shop

        Information
        Datasheet Video Manual
        What else did others buy
        Genuinegoods

        • Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine DetectorOverview

        • Specifications
        • Comments
        • FAQs
        SK/MIC-800-F2-Y/10000
        Portable fluorine Detector
        • SK/MIC-800-F2-Y/10000 Portable fluorine Gas Detector, fluorine gas F2 electrochemistry 10000ppm
        • SK/MIC-800-F2-Y/10000 Portable fluorine Gas Detector, fluorine gas F2 electrochemistry 10000ppm Figure 1
        • SK/MIC-800-F2-Y/10000 Portable fluorine Gas Detector, fluorine gas F2 electrochemistry 10000ppm Figure 2
        Detection gas fluorine F2, range 0~10000ppm, resolution 0.1ppm, detection principle electrochemistry, Operating Mode pump suction, sampling accuracy ≤ 3% F.S, repeability 3% F.S

        SK/MIC-800 Series Handheld Gas Detector ApplicationsEFM ultra-low power consumption 32-bit ARM, the sensor adopts a professional imported catalytic combustion sensor, sensor partThe two-stage high-precision low-temperature drifting amplifier and high-stability power processing circuit are used to ensure fast detection and accurate measurement of the instrumentAccurate, stable and repeatable, the instrument has reached the international professional and most stable Gas Detector and leak Detector. The instrument adopts ultraLarge full-color 3.5-inch TFT screen, support Chinese and English graphic menu operation, easy for users to operate.

        Features

        • Imported high-precision sensors;

        • It uses a high-precision low-temperature drifting amplifier and a stable power processing circuit.

        • TFT 3.5-inch full-color display, graphic menu, Chinese and English display, providing real-time detection trend analysis chart;

        • Data storage function, which can store 200,000 sets of data, and the storage interval time is adjustable;

        • USB interface for high-speed data transfer, which can download and print data;

        • Built-in long-life imported micro sampling pump, cleaning gas path through gear adjustment;

        • Explosion-proof qualification certification, explosion-proof grade: ExiaII.CT4

        • Shell two-color mold: non-slip, waterproof, dustproof, explosion-proof

        Features

        • Pumping detection method: divided into three gears, low-grade, mid-range and high-grade

        • Monitor the concentration of gases in the environment or confined spaces and give alarms

        • With self-calibration function, zero point calibration function, multi-point calibration function

        • With temperature and pressure compensation, it can well realize the compensation of gas concentration in different temperature and pressure environments

        • One-click factory reset function, which can avoid the trouble of misoperation

        • Gas concentration unit LEL, %LEL can be quickly switched to display;

        • It has a self-programming function and can set alarm parameters, STEL and TWA function parameters

        • It has two detection modes: normal detection mode and patrol mode;

        • The detection gas path has the function of automatic cleaning, which automatically prompts the failure of the instrument, the function of sensor calibration expiration and failure, and the maximum detectionValue, STEL, TWA and concentration values are displayed in real time

        Exterior Dimension Drawing

        Details of SK/MIC-800-F2-Y/10000 Portable Fluorine Detector Figure 1


        Series selection

        Detection of gasesRangeMaximum allowable errorMinimum readingResponse timeT90
        Combustible (EX)0-100%LEL＜±3%(F.S)0.1%LEL≤ 10 seconds
        Combustible (EX)0-100%Vol＜±3%(F.S)0.1%Vol≤ 10 seconds
        Methane (CH4)0-100%LEL＜±3%(F.S)0.1%LEL≤ 10 seconds
        Methane (CH4)0-100%Vol＜±3%(F.S)0.1%Vol≤ 10 seconds
        Oxygen (O2)0-30%Vol＜±3%(F.S)0.01%Vol≤ 10 seconds
        Oxygen (O2)0-100%Vol＜±3%(F.S)0.01%Vol≤ 10 seconds
        Oxygen (O2)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Nitrogen (N2)0-100%Vol＜±3%(F.S)0.01%Vol≤ 10 seconds
        Carbon Monoxide (CO)0-100ppm＜±3%(F.S)0.1ppm≤ 25 seconds
        Carbon Monoxide (CO)0-1000ppm＜±3%(F.S)0.1ppm≤ 25 seconds
        Carbon Monoxide (CO)0-2000ppm＜±3%(F.S)0.1ppm≤ 25 seconds
        Carbon Monoxide (CO)0-20000ppm＜±3%(F.S)1ppm≤ 25 seconds
        Carbon Monoxide (CO)0-100000ppm＜±3%(F.S)1ppm≤ 25 seconds
        Carbon dioxide (CO2)0-500ppm＜±3%(F.S)1ppm≤ 20 seconds
        Carbon dioxide (CO2)0-2000ppm＜±3%(F.S)1ppm≤ 20 seconds
        Carbon dioxide (CO2)0-5000ppm＜±3%(F.S)1ppm≤ 20 seconds
        Carbon dioxide (CO2)0-50000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Carbon dioxide (CO2)0-20%Vol＜±3%(F.S)0.01%Vol≤ 30 seconds
        Carbon dioxide (CO2)0-100%Vol＜±3%(F.S)0.01%Vol≤ 30 seconds
        Formaldehyde (CH2O)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Formaldehyde (CH2O)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Formaldehyde (CH2O)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Formaldehyde (CH2O)0-5000ppm＜±3%(F.S)1ppm≤ 50 seconds
        Ozone (O3)0-1ppm＜±3%(F.S)0.001ppm≤ 20 seconds
        Ozone (O3)0-5ppm＜±3%(F.S)0.001ppm≤ 20 seconds
        Ozone (O3)0-50ppm＜±3%(F.S)0.01ppm≤ 20 seconds
        Ozone (O3)0-100ppm＜±3%(F.S)0.01ppm≤ 20 seconds
        Ozone (O3)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Ozone (O3)0-30000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Ozone (O3)0-20mg/L＜±3%(F.S)0.01mg/L≤ 30 seconds
        Ozone Water (O3)0-20mg/L＜±3%(F.S)0.01mg/L≤ 30 seconds
        Hydrogen sulfide (H2S)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Hydrogen sulfide (H2S)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen sulfide (H2S)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen sulfide (H2S)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Hydrogen sulfide (H2S)0-10000ppm＜±3%(F.S)1ppm≤ 45 seconds
        Sulphur dioxide (SO2)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Sulphur dioxide (SO2)0-20ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Sulphur dioxide (SO2)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Sulphur dioxide (SO2)0-500ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Sulphur dioxide (SO2)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Sulphur dioxide (SO2)0-10000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Nitric Oxide (NO)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Nitric Oxide (NO)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Nitric Oxide (NO)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Nitric Oxide (NO)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Nitrogen dioxide (NO2)0-10ppm＜±3%(F.S)0.001ppm≤ 25 seconds
        Nitrogen dioxide (NO2)0-100ppm＜±3%(F.S)0.01ppm≤ 25 seconds
        Nitrogen dioxide (NO2)0-1000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Nitrogen dioxide (NO2)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Nitrogen Oxides (NOX)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Nitrogen Oxides (NOX)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Nitrogen Oxides (NOX)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Nitrogen Oxides (NOX)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Chlorine (CL2)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Chlorine (CL2)0-20ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Chlorine (CL2)0-200ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Chlorine (CL2)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Ammonia (NH3)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ammonia (NH3)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ammonia (NH3)0-1000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Ammonia (NH3)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Ammonia (NH3)0-100%LEL＜±3%(F.S)0.1%LEL≤ 10 seconds
        Hydrogen (H2)0-100%LEL＜±3%(F.S)0.1%LEL≤ 10 seconds
        Hydrogen (H2)0-1000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Hydrogen (H2)0-20000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Hydrogen (H2)0-40000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Hydrogen (H2)0-100%Vol＜±3%(F.S)0.01%Vol≤ 20 seconds
        Helium (He)0-100%Vol＜±3%(F.S)0.01%Vol≤ 20 seconds
        Argon (Ar)0-100%Vol＜±3%(F.S)0.01%Vol≤ 20 seconds
        Xenon (Xe)0-100%Vol＜±3%(F.S)0.01%Vol≤ 20 seconds
        Hydrogen cyanide (HCN)0-30ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen cyanide (HCN)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen chloride (HCL)0-20ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen chloride (HCL)0-200ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Phosphine (PH3)0-5ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Phosphine (PH3)0-25ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Phosphine (PH3)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Chlorine dioxide (CLO2)0-1ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Chlorine dioxide (CLO2)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Chlorine dioxide (CLO2)0-200ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethylene Oxide (ETO)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethylene Oxide (ETO)0-1000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        ethylene oxide(ETO)0-100%LEL＜±3%(F.S)1%LEL≤ 30 seconds
        Phosgene (COCL2)0-1ppm＜±3%(F.S)0.001ppm≤ 20 seconds
        Phosgene (COCL2)0-50ppm＜±3%(F.S)0.01ppm≤ 20 seconds
        Silane (SiH4)0-1ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Silane (SiH4)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Fluorine (F2)0-1ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Fluorine (F2)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Fluorine (F2)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen fluoride (HF)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen fluoride (HF)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen bromide (HBr)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethylborane (B2H6)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Hydrogen arsenide (AsH3)0-1ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Hydrogen arsenide (AsH3)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen arsenide (AsH3)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Germanane (GeH4)0-2ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Germanane (GeH4)0-20ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrazine, hydrazine (N2H4)0-1ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Hydrazine, hydrazine (N2H4)0-300ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Tetrahydrothiophene (THT)0-100mg/m3＜±3%(F.S)0.01mg/m3≤ 60 seconds
        Bromine gas (Br2)0-10ppm＜±3%(F.S)0.001ppm≤ 30 seconds
        Bromine gas (Br2)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Bromine gas (Br2)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Acetylene (C2H2)0-100%LEL＜±3%(F.S)0.1%LEL≤ 30 seconds
        Acetylene (C2H2)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Acetylene (C2H2)0-1000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Ethylene (C2H4)0-100%LEL＜±3%(F.S)0.1%LEL≤ 30 seconds
        Ethylene (C2H4)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethylene (C2H4)0-2000ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        acetaldehyde0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethanol (C2H6O)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Ethanol (C2H6O)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Methanol (CH6O)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Methanol (CH6O)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Carbon disulfide (CS2)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Carbon disulfide (CS2)0-5000ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Acrylonitrile (C3H3N)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Acrylonitrile (C3H3N)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Methylamine (CH5N)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Classical Qi (I2)0-50ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Styrene (C8H8)0-200ppm＜±3%(F.S)0.1ppm≤ 30 seconds
        Styrene (C8H8)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Vinyl chloride (C2H3CL)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Trichloroethylene (C2HCL3)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Perchloroethylene (C2CL4)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Laughing Gas (N2O)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Nitrogen trifluoride (NF3)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Hydrogen peroxide (H2O2)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Methyl bromide (CH3Br)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Methyl bromide (CH3Br)0-30000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Methyl bromide (CH3Br)0-200g/m3＜±3%(F.S)0.1g/m3≤ 30 seconds
        Sulfuryl fluoride (SO2F2)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Sulfuryl fluoride (SO2F2)0-5000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Sulfuryl fluoride (SO2F2)0-10000ppm＜±3%(F.S)1ppm≤ 30 seconds
        Benzene (C6H6)0-10ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Benzene (C6H6)0-100ppm＜±3%(F.S)0.01ppm≤ 30 seconds
        Benzene (C6H6)0-2000ppm＜±3%(F.S)1ppm≤ 30 seconds


        VS

        Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine DetectorSpecifications

        LIST VALUE
        Detection gas Fluorine F2
        range 0~10000ppm
        Resolution 0.1ppm
        Sensors principle electrochemistry
        Operating Mode Pump suction
        Sampling Accuracy ≦3%F.S
        Sexual repeability 3%F.S
        Long term drift ≤±3% (F.S/年)
        Response time ≤10S
        Warm-up period 30S
        Operating Current ≤50mA
        data storage USB data collection, 300,000 group information storage
        service life 3 years
        Operating Pressure 86kpa-106kpa
        Shell material Anti-corrosion plastic, aluminum alloy
        Operating temperature -30~50℃
        Environment humidity 10~95% RH non-condensing
        Storage temperature -30~70℃
        Dimensions 228 * 84 * 50.5mm excluding sampling tube
        Weight 1.5kg
        Explosion-proof sign Exia II CT4

        Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine Detector Packing list

        Portable detector X1, sampling tube X1, certificate X1, detector manual X1, charger X1

        [Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

        FAQ

        [Q]
        Is the price listed on the website the final cost for overseas purchases?
        [A]
        No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
        [Q]
        What is the specific process for purchasing the product?
        [A]
        First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
        [Q]
        What should I do if the instrument I purchase needs repair?
        [A]
        After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
        +Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine Detector Big data
          +Skyeaglee SK/MIC-800-F2-Y/10000 Portable fluorine DetectorStandard
          +Navigation
          Skyeaglee
          SK/MIC-800-F2-Y/10000 Portable fluorine Gas Detector, fluorine gas F2 electrochemistry 10000ppm
          Service
          Order Guide
          Payment & Shipping
          After-sales
          Cooperation
          About Us
          Focus on online sales of Lab Testing Instruments

          CopyRight © NBchao.Com 2012-2024, All Rights Reserved.
