Japan OSP-50/400 scraping reticulated stick WFT 50μm length 400mm

300Mm application width, 50μm film WFT, rod diameter is 10mm, can be manually or automatically scraped, hand width 50 + 50mm, material 304 stainless steel.

Brand

SKU: NB003797

OSP

Model

Price

$ 172.00

Promotion

Service

The delivery and service By NBchao.Com

Get Quote

OSP shopSE

Information

Datasheet RFQ Contract Video Catalog Manual

What else did others buy

Leneta Form 7B sagging and levelling test cardboard 194 x 289 mm 250 sheets/box

$ 309.00
UK RK KHC.21 Drawdown Plate for Better Repeatability and Proofing

$ 240.00

Genuinegoods

OSP OSP-50/400 coating rodOverview
Specifications
Comments
FAQs

OSP-50/400

coating rod

300Mm application width, 50μm film WFT, rod diameter is 10mm, can be manually or automatically scraped, hand width 50 + 50mm, material 304 stainless steel.

Japan OSP-50/400 scraping anilox bar is suitable for coating width of 300mm (Total length is 400mm) and film thickness of 50μm.

OSP-50 extrusion coating rod animation operation video

OSP-50 Extrusion Coating Rod Product Specifications

Features and advantages of OSP-50 extrusion coating rod

OSP-50 Coating Rod Groove Shape

OSP-50 coating rod with high coating precision

Applications of OSP-50 Extrusion Coating Rod

Why choose NBCHAO Mall

Real shot of OSP-50 extrusion coating rod 1

Real shot of OSP-50 extrusion coating rod 2

The real picture of the handle of OSP-50 extrusion coating rod

Optional

Note: Click on the accessory picture to view Details.

OSP OSP-50/400 coating rodSpecifications

LIST	VALUE
Production process	Formed
WFT	50µm
diameter	10mm
Total length	400mm
Application width	300mm
Grip width	50+50mm
material	304 stainless steel

OSP OSP-50/400 coating rod Packing list

Stainless Steel Main Rod X1, Transparent External Encasement Hose X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

Can water-based paints be applied to glass slides with Mayer Rods?

[A]

Yes, there are many cases of wire rod Moulding for water-based paint.

[Q]

Is there a 50 micron OSP reticulated stick?

[A]

Hello, yes, OSP-50/250, OSP-50/400, OSP-50/60 are all film Film thickness 50μm, which is the different width of Spreader.

[Q]

To meet the GB/T13217.1 film scraper

[A]

OSP-50/400 film scraper, please refer to it.

[Q]

Is it possible to film the fabric with a rod? If so, how?

[A]

Fabric can be coated, a method of operation is, for example, UV curing Coating, the fabric dip coating, and then using Mayer Rods scrape off the surface of the fabric excess Coating, to ensure that the wet film thickness of the fabric surface is a specific type of wet film, then in ultraviolet curing machine curing, film thickness to obtain a specific film.

[Q]

50-80Um dry film, wire rod and handle with a total length of 400mm, is this suitable?

[A]

Hello, the film thickness marked on the Spreader stick is wet film, and dry film needs to be calculated according to your solid parts. In addition, the OSP400mm long wire rod does not have a handle. If you need a handle, please choose OSP L250 series. Thanks for your consultation.
