YiHeng BDW-86L390 ultra-low temperature freezerSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | -50~-86℃ |
| Studio Volume | 390L |
| insulation layer thickness | 126mm |
| Dimensions | 909*797*1990mm |
| Interior size | 589*505*1310mm |
| Door size | 1600*1603mm |
| Enclosure Material | Spray steel plate |
| Inner chamber material | 304 stainless steel |
| Number of inner doors | 4 |
| Shelf (std.) | 3pcs |
| Delamination number | 4 |
| Standard number of freezer racks | 16 |
| Number of frozen boxes | 240 |
| padlock hole | Yes. |
| Mechanical lock | Yes. |
| Data Logging | Yes. |
| spare battery | Yes. |
| Box temperature transducer | Yes. |
| Break Vacuum | Yes. |
| Anti-condensation door frame heating | Yes. |
| Anti-condensation door frame heating | Yes. |
| Controller type | touch screen |
| refrigerant | HCFC-free |
| Power Supply | AC220/50 |
| rated power | 1500W |
| Weight | 318kg |
| Condensation high temperature alarm | Yes. |
| Power failure alarm | Yes. |
| Sensors fault alarm | Yes. |
| Low battery alarm | Yes. |
| High temperature/low temperature alarm in the box | Yes. |
| Open the door and call the police. | Yes. |
| noise | ≤53dBA |
| Cooling rate | ≤5h |
| Characteristic point temperature | -86 |
| Temperature Uniformity | ≤6℃ |
| certification | CE, RoHs, medical apparatus registration Certificate |
YiHeng BDW-86L390 ultra-low temperature freezer Packing list
host x1, instruction manual x1, packing list x1, certificate x1.
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
