KORNO MOT500-CO2-Y carbon dioxide concentration Detector

Description

MOT500-CO2-Y series CO2 concentration Detector is suitable for CO2 gas concentration detection and analysis in various environments, using non-spectroscopy infrared NDIR gas sensor and microcontroller technology, with fast response, high measurement accuracy, good stability and repeatability. The instrument adopts 2.4-inch industrial-grade color screen, which completely displays various technical indicators and gas concentration values; at the same time, it has a variety of strong circuit protection functions to effectively prevent the damage of the instrument caused by various human factors and uncontrollable factors; you can choose the online environmental testing platform developed by our company, and access the Municipal Environmental Protection Bureau, enterprise server, central control alarm, user mobile phone, Baidu cloud, Baidu cloud and other transmission methods through 3-4 core cables, optical fibers, network cables, Wiff, Bluetooth, GPRS, mobile phone APP, etc. Alibaba Cloud, etc., combined with powerful data analysis software, can realize remote monitoring, remote control, remote alarm, and can perform real-time data query, historical data query, data export, data printing and other operations on users' computers, mobile phones, Ipads and other devices

Features

(1) Ultra-low-power 32-bit microprocessor using a new semiconductor nanoprocess

(2) 2.4-inch industrial-grade color screen with a resolution of 320x240

(2) PPM, %VOL, mg/m3 can be switched freely

(3) A variety of signal output options: 4-20mA, RS485, 0-5V, 0-10V, frequency signal, switching signal

A variety of transmission methods are available: 3-4 core cable, optical fiber, network cable, GPRS transmission, wireless transmission, video transmission

A variety of data receiving methods: user computer, control alarm, PLC, DCS, mobile phone, tablet computer, etc

(4) It has the function of status indication and comes with 4 sets of LED status indicators

(5) It has the functions of over-Voltage protection, lightning protection, short-circuit protection, reverse connection protection, anti-static interference, anti-magnetic field interference, etcAnd it has an automatic recovery function to prevent any damage to the instrument caused by external reasons, man-made reasons, natural disasters, etc

(6) With temperature and humidity detection function, it can detect the temperature and humidity value of gas in the field or pipeline (optional)

(7) Full software automatic calibration, sensor up to 6 levels of target point calibration function, to ensure the accuracy and linearity of measurement, and with data recovery function

(8) Full Chinese/English operation menu, simple and practical, with temperature compensation function

(9) Infrared remote control can be optional, and the instrument can be operated remotely without opening the cover

Transmission mode

(1) Cable transmission: 3-core, 4-core cable, long-distance transmission (1-2 km)

(2) TCP/IP transmission: support TCP/IP protocol, use optical fiber, network cable, long-distance real-time transmission through intranet, extranet (optional)

(3) GPRS transmission: built-in GPRS module, real-time remote transmission of data, not limited by distance (optional)

(4) Wireless transmission: support 433Mhz, radio station transmission mode, transmission distance 2-10Km, depending on different power (optional)

(5) Video transmission: it can support security surveillance cameras, and when the equipment is alarmed, on-site capture and evidence collection (optional)

Signal output

(1) 4-20mA signal: standard 16-bit precision 4-20mA output chip, transmission distance 1Km

(2) RS485 signal: using standard MODBUS RTU protocol, transmission distance 2Km

(3) Voltage signal: 0-5V, 0-10V output, can be set by yourself

(4) Pulse signal: also known as frequency signal, frequency range adjustable (optional)

(5) Switching signal: 1 group of relays as standard, optional 2 sets of relays, passive contacts, capacity 220VAC 3A/24VDC 3A

Enforce the standard

GB3836.1-2010

GB3836.2-2010 "Explosive atmospheres – Part 2: Equipment protected by flameproof enclosure "d"

machine X1, manual X1, certificate X1, warranty card X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
