Pushen ISO-8 #desktop Flow Cup with bracket, need to be customized
The Pushen ISO-8 #Benchtop Viscosity cup is a No. 8 ISO cup with an outflow aperture of 8mm. The No. 8 Benchtop Viscosity cup is suitable for the measurement of Viscosity of Coatings, varnishes and Miscellaneous similar products.
Pushen
ISO-8#
-
QNB ISO Flow Cup set YONGLIDA contains 3, 4 and 6 Flow Cups
$ 229.00 -
TQC VF2185 Handheld ISO Viscosity Cup aluminum alloy/5mm
$ 389.00 -
TQC VF2024 Viscosity Cup filter, stainless steel 4mm
$ 145.00 -
JINGKELIAN QND-1 Viscometer 1 Viscosity Cup
$ 152.00 -
TQC VF2074 immersion Viscosity Cup 5mm filter
$ 352.00
ISO CupIntroduction
The PSH ISO cup is a benchtop Viscosity Cup with a stand, and five different models are designed according to different measuring apertures: No. 3, No. 4, No. 5, No. 6,No. 8 (customized), the measured aperture is 3mm, 4mm, 5mm, 6mm,8mm.The production designer of the PSH ISO Cup meets the standardASTM D 5125, ISO 2431, is a required testing instrument for laboratory testing of viscosity.
Made of anodized aluminium with a stainless steel pore size, the PSCHEN ISO cup is used to measure the viscosity of coatings, varnishes and other similar products.
Parameters
| Model | Outflow Aperture (mm) | Measuring range (cSt) | Finish Time(s) | The width of the cup | Cup height | weight | Meets standards | wrap |
| Number 3 | 3 | 7-42 | 30-100 | 56mm | 86mm | 268g | ASTM D 5125，ISO 2431 | A Viscosity Cup, a holder |
| Number 4 | 4 | 34-135 | 25-100 | |||||
| Number 5 | 5 | 91-326 | 25-100 | |||||
| Number 6 | 6 | 188-684 | 25-100 | |||||
| Number 8 | 8 | -- | Customized |
Viscosity and definition of Viscosity Cup
Viscosity: The ability of a liquid to hinder its tendency to flow is known as viscosity. For the coatings industry, viscosity is a critical parameter.
Viscosity cups: Allow a liquid to flow through the nozzle, often using this method to measure and grade its viscosity relatively.
The dynamic viscosity value is usually expressed in the number of seconds in which the flow has been completed, but it can also be converted to centistokes by the viscosity conversion dial.
Viscosity unit
The kinematic viscosity value is usually expressed in the number of seconds of the flow out, but it can also be converted to centistokes by the viscosity conversion dial.
The unit of kinematic viscosity is stokes, Stokes, when the fluid viscosity is 1P (poise), the density is 1g/cm3 and the kinematic viscosity is 1 stokes.
cSt is an abbreviation for centistokes and is called centis, i.e. one hundredth of 1 stokes. CSt is the smallest unit of kinematic viscosity.
Precautions
A stopwatch with high accuracy is required for use.
Meets standards
Coating ISO cups are made according to ASTM D 5125, ISO 2431 "Determination of Flow Time in Flow Cups" for basecoats and varnishes.
Actual picture of the product
Pushen ISO-8# Flow cup with bracketSpecifications
| LIST | VALUE |
|---|---|
| Viscosity range | 7~42cSt |
| outflow time | 30~100s |
| Flow hole diameter | 3mm |
| Cup height | 86mm |
| Cup width | 56mm |
| Cup body material | Aluminum anode oxidation |
| Filter material | stainless steel |
| Applicable standard | ASTM D5125,ISO 2431 |
| Certificate | without |
| Weight | 268g |
Pushen ISO-8# Flow cup with bracket Packing list
Viscosity cup x1, bracket x1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
