1/1000 Precision Balance Tianma JA4003 Range up to 400g External Correction
0~400G, Readability 20mg, Adjustment external calibrated, Stabilization time ≤ 5s, accuracy class II, Pan Size ≤ 90mm
TianMa-
XINGYUN JA5000C Precision Balance Weighing, Counting, Unit Conversion 5000g/0.01g
$ 268.00 -
YUEPING JA51001 Precision Balance 5100g/0.1g
$ 406.00 -
XINYUN XY600C Precision Electronic Balance 610g/0.01g External Calibration
$ 133.00 -
HUAZHI DTY-B1200 Electronic Analytical Balance dual range is 1200g/2200g
$ 344.00 -
YUEPING JA1003C Auto Internal Cal Analytical Balance
$ 490.00
Overview of JA4003 1/1000 precision balance
JA4003 one-thousandth precision balance is a precision analytical balance produced by Tianma with a modular electromagnetic force balance sensor. The accuracy is 0.001g. The maximum capacity of JA4003 one-thousandth precision balance is 400g, and it is equipped with an external calibration weight of 200g.
Structural diagram of JA4003 one-thousandth precision balance

One-thousandth precision electronic balance 1mg features
1. Four levels of shock resistance;
2. RS232 interface module;
3. High sensitivity touch button;
4. Built-in lower weighing hook;
5. Two-way communication with independent reset and tare buttons;
6. Fast weighing, the weighing speed is several times faster than ordinary balances, and the weighing speed can be adjusted, and the display mode can be adjusted with dynamic temperature compensation;
7. High intelligence. Can be tare within the full range, automatic zero tracking adjustable, overload, underload display, automatic fault diagnosis sensor overload protection;
8. Various functions such as technical functions are available for selection;
9. Modular electromagnetic force balance sensor;
10. Range indication blue large-screen LCD display;
11. The operation is simple and easy to learn, and the mass unit conversion provides the function of selecting the unit arbitrarily. The user can arbitrarily choose a variety of commonly used international mass units provided by the software.
One-thousandth precision electronic balance 1mg display



TianMa JA4003 JA Series Precision BalanceSpecifications
| LIST | VALUE |
|---|---|
| Weighing range | 0~400g |
| readability Accuracy | 20mg |
| Calibrating function | Externally calibrated |
| Settling time | ≤5s |
| Operating Conditions | 15~ 30 ℃, Temperature Fluctuation is not more than 5 ℃/h |
| Pan size | Ф90mm |
| Power | AC adapter 220V 50Hz output DC9V-2.2A |
| Instrument net Weight | 7200g |
| Dimensions | 340*215*350mm |
| Accuracy class | Ⅱ |
| Actual Graduation d | 1mg |
| Verification Graduation e | 0.01g |
| Repeatability Error | ±0.001g |
| MPE | Load m (denoted by verification Graduation e) |
| ±0.5e | 0≤m≤50000 |
| ±1.0e | 50000<m≤200000 |
| ±1.5e | 200000<m |
| Relative Humidity | 40%~80% |
| Wind Shield size | 225*220*265mm |
TianMa JA4003 JA Series Precision Balance Packing list
host X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
