HUITAI BPG-9920A Blast drying oven Volume 1000L with test hole 50mm
With test hole 50mm, Inner chamber dimensions 1000 * 655 * 1520mm, volume 1000L, liner with mirror stainless steel, box shell with good Cold rolled steel plate manufacturing, surface electrostatic spray.
HuiTai
BPG-9920A + test hole 50mm
BPG-9140A + test hole 50mm
BPG-9070A + test hole 50mm
BPG-9240A + test hole 50mm
BPG-9620A + test hole 50mm
BPG-9420A + test hole 50mm
-
BENTING BGLZ-125BE gravity convection Drying Oven
Login -
CHINA DGG-9140A Desktop Drying Oven 200 ℃/136L
$ 472.00 -
MODERNER ZGX-6020 Vacuum Oven temperature control RT + 10~250 ℃
Login -
HUITAI BPG-9140A Laboratory oven volume 136L with test hole 50mm
$ 853.00 -
BENTING C101-1AB experimental Forced Air Drying Oven 250 ℃/70L 101 oven
Login
Applications
Huitai BPG-9920A desktop precision Forced Air Drying Oven is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.
Features
1. Large-screen LCD display, multiple sets of data displayed on one screen, menu-style operation interface, easy to understand and easy to operate. (standard configuration)
2. The fan speed control mode is adopted to improve the temperature uniformity of the working room.
3. The self-developed air duct circulation system is adopted to automatically discharge the water vapor inside the box, and there is no trouble of manual adjustment.
4. It adopts a microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, and the temperature control is accurate and reliable.
5. The inner tank is made of mirror stainless steel, the shelf bracket can be installed and disassembled freely, and the semi-circular four-corner design makes cleaning more convenient.
6. The Oven Casing is made of high-quality cold-rolled steel plate, and the surface is electrostatically sprayed.
7. Independent temperature limit alarm system, which will be automatically interrupted when the temperature exceeds the limit, so as to ensure the safe operation of the experiment without accidents. (optional)
8. With RS485 interface, it can be connected to the Recorder and computer, and can record the changes of temperature parameters. (optional)
Optional
Intelligent program controller
Independent temperature limit controller
Embedded printer
RS485 interface and special software
Test hole 25mm/50mm
Comparison of parameters of BPG series precision Forced Air Drying Oven
| model | Studio size(mm) | volume | Standard loading bracket |
| BPG-9070A | 400×425×445 | 80L | 2pcs |
| BPG-9140A | 450×550×550 | 136L | 2pcs |
| BPG-9240A | 500×600×750 | 225L | 2pcs |
| BPG-9420A | 600×550×1300 | 420L | 3pcs |
| BPG-9620A | 800×640×1290 | 620L | 4pcs |
| BPG-9920A | 1000×600×1600 | 1000L | 4pcs |
| Other parameters | |||
| Voltage | AC220V 50HZ | ||
| Temperature control range | RT+10~300℃ | ||
| Constant temperature fluctuation | ±0.5℃ | ||
| temperature resolution | 0.1°C | ||
| Timer Range | 1~9999min | ||
HuiTai BPG-9920A + test hole 50mm Precision blast Drying OvenSpecifications
| LIST | VALUE |
|---|---|
| Power | AC 220V 50Hz |
| Temperature range | RT+10~300℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Input Power | 6000W |
| Interior size | 1000*600*1600mm |
| Dimensions | 1180*800*2150mm |
| Volume | 1000L |
| Shelf (std.) | 4pcs |
| Timer | 1~9999min |
HuiTai BPG-9920A + test hole 50mm Precision blast Drying Oven Packing list
host X1, fuse X2, rack X2, certificate X1, manual X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
