Defelsko PosiTest CH ISO2409 cross-cut test blade 3mm/6 teeth
Number of cutter teeth 6, cutter tooth spacing 3mm, cutter head material hardened, apply standard ISO 2409.
Defelsko
CHBLADE6X3
-
TRUIT TR 5006/1 coating cross-cut plate cross-cut number 11
$ 148.00 -
Erichsen 295/II Cross Hatch Cutter Set 6 teeth/2mm
$ 987.00 -
HUITAO HT-430P electric cross-cut tester, desktop PLC control automatic cross-cut adhesion testing
$ 8912.00 -
TQC SP1706 cross-cut cutter head 11 teeth, spacing 1.5mm for CC2000/CC3000 series
$ 387.00 -
TQC SP3020 adhesion tape 3M adhesion 7.6 N/cm
$ 171.00
Introduction
Cross-scratch adhesion TesterAccording to ISO 2409 and ASTM D3359, the ability of the coating to resist separation from the substrate is determined when cutting a lattice pattern on the coating.
All tools and accessories needed to perform the cross-scratch test are included.Ergonomically designed tool grip with non-slip grip for comfortable all-day use.The rotatable cutting head ensures proper positioning and uniform cutting surface pressure.Easy-to-change, hardened steel blade with 4 cutting edges for longer testing.Tapes are available in accordance with ISO 2409 or ASTM D3359.
Replacement blades
| Blade model | specification | |
| CHBLADE6X1 | 1mm/6 teeth | ISO 2409 |
| CHBLADE6X2 | 2mm/6 teeth | ISO 2409 |
| CHBLADE6X3 | 3mm/6 teeth | ISO 2409 |
| CHBLADE11X1 | 1mm/11 teeth | ASTM D3359 |
Defelsko CHBLADE6X3 Cross-cut Adhesion Tester BladeSpecifications
| LIST | VALUE |
|---|---|
| Number of teeth | 6 teeth |
| Tooth spacing | 3mm |
| Cutter head material | Harden just |
| Application standard | ISO 2409 |
Defelsko CHBLADE6X3 Cross-cut Adhesion Tester Blade Packing list
Blade X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
