CHINA DK-450A electrothermal Thermostatic Water Bath temperature control 65 ℃ volume 25L
Liner stainless steel, size 450x300x190mm, Temperature range + 5 ℃~ 65 ℃, Temperature resolution 0.1 ℃, Sensors fault and over-temperature alarm function, support timing.
Factory
DK-450A
DK-450B
DK-600B
DK-600A
-
FANGRUI DC1506N (W) Horizontal low temperature constant temperature Water Bath Temperature range -15~ 100 ℃
$ 755.00 -
Shangtian Jingyi DC-0510 Low Temperature Thermostatic Bath Digital display Low Temperature Thermostatic Bath -5 ℃/10L
$ 1190.00 -
YIHENG DK-8AXX electrothermal Thermostatic Water Bath Input Power is 600W Volume 12L
$ 323.00 -
Shangtian Jingyi DHC-1010 high-Low Temperature Circulating Bath, hot and cold Constant Temperature Water/Oil Bath -10~160 ℃/10L
$ 1414.00 -
NELE DC-3006 Thermostatic Bath vertical 6L/-30 ℃ +/- 0.05 ℃
$ 1039.00
Applications
It is used for precision constant temperature and auxiliary heating in medical and health care, medical schools, industrial and mining enterprises and scientific research institutions.
Features
1. It adopts stainless steel inner tank and top cover, with novel and beautiful appearance. Use high-performance CPU processing chips and high-sensitivity, high-precision platinum resistors
2. The temperature control system of the sensor makes the temperature control more precise and the operation more convenient. It has sensor fault alarm, over-temperature alarm, and self-diagnosis dynamic control.
3. Temperature display correction, parameter memory and timing function up to 999 minutes
DK series parameter comparison table
| model | Temperature control range | Inner tank size |
| DK-450A | Room temperature +5℃~65℃ | 450x300x190mm |
| DK-600A | Room temperature +5℃~65℃ | 600x300x170mm |
| DK-450B | Room temperature +5℃~99℃ | 450x300x190mm |
| DK-600B | Room temperature +5℃~99℃ | 600x300x170mm |
| DKB-450A | Room temperature +5℃~65℃ | 450x300x190mm |
| DKB-600A | Room temperature +5℃~65℃ | 600x300x170mm |
| Other parameters | ||
| Temperature resolution | 0.1℃ | |
| Internal materials | 304 stainless steel | |
| External materials | 08F | |
| sensor | High precision platinum resistance sensor | |
Factory DK-450A Electrothermal Thermostatic Water BathSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | Room temperature + 5 ℃~ 65 ℃ |
| Temperature Fluctuation | ±0.3℃ |
| Temperature Resolution | 0.1℃ |
| Temperature transducer | High-Precision Platinum Resistance Sensors |
| Tank Volume | 25L |
| Tank Material | 304 stainless steel |
| Tank Size | 450x300x190mm |
| Total Power | 1000W |
| Power | AC220V±10% 50Hz±1Hz |
| Timer | 0~9999 minutes |
| Dimensions | 600*340*300mm |
| Net Weight | 15.5kg |
| external material | 08F |
| Controller | Liquid crystal display, push-button, fuzzy PID control technology for microprocessor temperature control |
| Ambient Temperature | 5~30℃ |
| Relative Humidity | ≤80% |
Factory DK-450A Electrothermal Thermostatic Water Bath Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
