HANNA HI4105 ISE Ion selective electrode CO2
Electrode type Carbon dioxide [CO2], test range 0.02 M to 4 × 10-4 M, 880 to 17.6 ppm, operating range 4.2-5 pH 0-40 ℃, applied mineral water/wine/cell fostering.
HANNA
HI4105
HI4104
HI4103
ISE ion selective electrode is a high-precision electrode for specific ion measurement, which is widely used in environmental monitoring, food analysis, industrial process control, and other fields. Each sensor is designed for a specific ion and provides accurate measurements at different concentrations and pH ranges. Models listed in the table include ammonia, cadmium, calcium, carbon dioxide, chloride, fluoride, iodide, lead/sulfate, nitrate, and potassium plasma electrodes, each with its own specific testing range and application area. For example, the HI4101 ammonia electrode is suitable for wastewater treatment, the HI4103 cadmium electrode is used in the electroplating and battery industries, and the HI4113 nitrate electrode is used for the detection of nitrates in wastewater and food. These sensors are capable of operating at different temperatures and pH conditions, ensuring measurement accuracy in a variety of complex environments.
| ISE ion-selective electrode | ||||
| Model | Type of electrode | Test Scope | Scope of operation | apply |
| HI4101 | Ammonia [NH₃/NH₃-N] | 1.0 M to 1×10-6 M 17000 to 0.02 ppm 14000 to 0.014 ppm | pH＞11 0-40℃ | Wastewater treatment |
| HI4103 | Cadmium [Cd] | 0.1 M to 1×10-7 M 11200 to 0.01 ppm | 2-12.5 pH 0-80℃ | Plating/Batteries |
| HI4104 | Calcium [Ca2+] | 1.0 M to 3×10-6 M 40080 to 0.12 ppm | 4-10 pH 0-40℃ | Milk/serum/soil |
| HI4105 | Carbon dioxide [CO2] | 0.02 M to 4×10-4 M 880 to 17.6 ppm | 4.2-5.2 pH 0-40℃ | Mineral water/wine/cell culture raise |
| HI4107 | Chloride [Cl-] | 1.0 M to 5×10-5 M 35450 to 1.8 ppm | 2-11 pH 0-80℃ | Food/Water/Concrete |
| HI4110 | Fluoride【F-】 | Saturation to 1×10-6 m Saturation to 0.02 ppm | 5-8 pH 0-80℃ | Drinking Water / Milk / Factory / toothpaste |
| HI4111 | Iodide [I-] | 1.0 M to 1×10-7 M 127000 to 0.01 ppm | 2-13 pH 0-80℃ | Emulsifiers/foods |
| HI4112 | Lead/sulfate 【Pb2+/SO4 2-】 | 0.1 M to 1×10-6 M 20700 to 0.21 ppm | 4-7 pH 0-80℃ | Electroplating industry/environmental monitoring |
| HI4113 | Nitrate [NO3-] | 0.1 M to 1×10-5 M 6200 to 0.62 ppm | 3-8 pH 0-40℃ | Wastewater/meat/vegetables |
| HI4114 | Potassium [K+] | 1.0 M to 1×10-6 M 39100 to 0.039 ppm | 1.5-12 pH 0-40℃ | Wastewater/wine/soil |
HANNA HI4105 ISE Ion selective electrodeSpecifications
| LIST | VALUE |
|---|---|
| Electrode type | Carbon dioxide [CO2] |
| test range | 0.02 M to 4×10-4 M、 880 to 17.6 ppm |
| operating range | 4.2-5.2 pH 0-40℃ |
| application | Mineral water/wine/cell culture |
HANNA HI4105 ISE Ion selective electrode Packing list
host X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
