KORNO MOT500-CO-Y Stationary carbon monoxide Detector, measuring range 0-50ppm
Detection gas carbon monoxide (CO), imported electrochemistry /NDIR infrared carbon monoxide gas Sensors, Measurement range 0-50ppm, Linearity ≤ +/- 1%, detection accuracy ≤ +/- 1%
KORNO
MOT500-CO-Y
Introduction
MOT500 is an online intelligent Gas Detector (transmitter) with 2.4-inch IPS color screen display, which adopts large-scale integrated circuit technology and is designed by international standard intelligent technology level, and is a completely intelligent gas transmitter designed by digital and analog hybrid communication technology. The intelligent gas transmitter has high stability, communication and self-diagnosis functions, easy installation and maintenance, and meets the requirements of high reliability of equipment for industrial site safety monitoring. MOT series intelligent gas transmitters are widely used in petroleum, chemical, metallurgy, refining, gas transmission and distribution, biochemical and other industries, the instrument is compatible with various control alarms, PLC, DCS and other control systems, can realize remote detection, control, alarm, with computer data storage, data analysis and other functions.
Instrument features
It adopts the new semiconductor nano process ultra-low power 32-bit microprocessor and 24-bit ADC data acquisition chip
It adopts a 2.4-inch IPS industrial-grade high-definition large screen with a resolution of 320x240
1-6 sensors can be supported according to customer needs (Note: 4-20mA output is not supported for all-in-one composite gas)
PPM and mg/m3 can be switched freely
Multiple signal output modes are standard:
1. 4-20mA output (single 1 sensor): standard 16-bit precision 4-20mA output chip, transmission distance of 1Km (optional 0-5V or 0-10V Voltage output mode)
2. RS485 output: using standard MODBUS RTU protocol, the transmission distance is 1.2Km, and the repeater can extend the transmission distance
3. Relay output: 2 sets of passive (dry junction) outputs (normally open/NO and normally closed/NC) are standard
A variety of signal transmission methods are available: 3~5 core cable, network cable, 433Mhz wireless transmission, GPRS wireless transmission
Up to 6 levels of target point calibration function of the sensor to ensure the accuracy and linearity of the measurement,
Manual zero and target calibration, factory reset, and analog 4mA and 20mA output calibration are available
It has the functions of wide Voltage input, short-circuit protection, reverse connection protection, anti-static interference, anti-magnetic field interference, etc., and has the function of automatic recovery to prevent the instrument from being damaged by any external causes, man-made reasons, natural disasters, etc
The instrument is compatible with all kinds of remote control equipment: PLC, DCS, control alarm, secondary instrument, etc
The shell is hard oxidized, explosion-proof and anti-corrosion, and can be used for a long time in any harsh environment.
The instrument can also be equipped with: temperature/humidity sensor, on-site sound and light alarm, etc
Features
Product Dimension Drawing
KORNO MOT500-CO-Y Carbon monoxide DetectorSpecifications
| LIST | VALUE |
|---|---|
| Detect gas | Carbon monoxide (CO), imported electrochemistry /NDIR infrared carbon monoxide gas Sensors |
| Measurement range | 0-50ppm |
| resolution | 0.01ppm |
| Response time | ≤ 20 seconds (T90) |
| Linearity | ≤±1% |
| detection Accuracy | ≤ +/- 1% (depending on the Sensors) |
| Zero drift | ≤ +/- 1% (F. S/year) |
| recovery time | ≤ 20 seconds |
| Repeatability | ≤±1% |
| gas expansion | Supports 1-6 Sensors (optional) |
| Explosion-proof certification | CNEx16.0547 |
| Protection level | IP65 |
| production license | Guangdong 00001052 (CMC metrology authentication) |
| Humidity | Optional accessories, temperature detection range: -25~ 60 ℃, Humidity detection range: 0~95% RH |
| Detection method | Diffusion, flow, pump suction optional |
| Installation method | Wall-mounted, pipeline type (thread size: M40X1.5mm), circulation type |
| signal output | ① 4-20mA signal: standard 16-bit Accuracy 4-20mA output chip, transmission distance 1Km ② RS485 signal: using standard MODBUS RTU protocol, transmission distance 2Km ③ Voltage signal: 0-5V, 0-10V output, can be set by yourself ④ Optional 4-20mA + Hart output ⑤ Switching signal: standard 2 sets of relays, optional third set of relays, passive touchpoint, Capacity 220VAC 3A/24VDC 3A |
| transmission method | ① Cable transmission: 3-core, 4-core cable, long-distance transmission (1-2 kilometers) ② TCP/IP transmission: support TCP/IP protocol, use optical fiber, network cable, long-distance real-time transmission through intranet, extranet (optional) ③ GPRS transmission: built-in GPRS module, real-time remote transmission of data, without distance restrictions (optional) ④ Wireless transmission: support 433Mhz, radio transmission mode, transmission distance 2-10Km, depending on different Power (optional) |
| receiving device | User computer, control alarm, PLC, DCS, mobile phone, tablet computer, etc. are optional |
| Alarm mode | On-site sound and light alarm, external alarm, remote Controller alarm, computer data collection software alarm, mobile app notification, SMS alarm optional |
| Alarm settings | ① Standard configuration two-level alarm, optional three-level alarm ② Gas Sensors can set two alarm modes of conventional high and low alarm and interval control, which can control the concentration range of gas ③ Temperature sensor can set the control range ④ Humidity Sensors can set the control range |
| shell material | Die casting aluminum + sand blasting oxidation/fluorocarbon paint, explosion-proof and anti-corrosion |
| Operating temperature | -30~50 ℃ (Humidity environment requires customization or optional pretreatment system) |
| Operating humidity | ≤ 95% RH, non-condensing |
| Working pressure | 0 ～ 100Kpa |
| Power Supply | 24VDC（12～30VDC） |
| size | 200*149*79mm(L×W×H） |
| Weight | 1.5Kg |
| execution standard | GB3836.1-2010 "Explosive environments - Part 1: Equipment - General requirements" GB3836.2-2010 "Explosive environments - Part 2: Equipment protected by flameproof enclosures" d " |
| optional range | 0-100、500、1000、2000、5000、10000、40000ppm |
KORNO MOT500-CO-Y Carbon monoxide Detector Packing list
host X1, calibration cover X1, manual X1, certificate X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
