Factory Direct LMJ-2.2 basket sand mill, manual lift 2.2KW Power

Introduction

LMJ series basket sand mill is a multi-functional equipment integrating grinding and dispersing processes. It is used in ink, colorant, dyes, coatings and other industries, and has the characteristics of energy saving, convenient operation and maintenance.

The machine is composed of an electrical cabinet, a rotating shaft, a Grinder, a pump blade, a dispersion disc and a grinding basket filled with a high-strength grinding medium. When working, the Grinder, pump blade and dispersion disc on the shaft and the shaft rotate at high speed, and the Grinder drives the grinding medium and the material to produce strong shear and collision to achieve the effect of grinding the material and dispersing the polymer, and at the same time, the ground material is sucked out of the grinding basket under the action of the strong suction of the pump blade, and then dispersed by the dispersion disc, so the reliable grinding effect can be obtained in a short time.

Operating Principle

Suction: The self-priming pump blade rotates at high speed, generating strong suction and vortex to suck the material into the grinding basket.

Dispersion: The centrifugal force generated by the high-speed rotation of the dispersion disc throws out the material sucked out of the grinding basket, accelerates the dispersion of the material, and forms a dispersed mixture with high material efficiency.

Dispersion grinding machine with good efficiency: self-priming pump blades rotate at high speed→ fine grinding in the grinding basket→ dispersion disc rotates at high speed to → discharge, disperse and circulate with high efficiency, solve the problem of material turning, avoid the dead angle of circulation, and the grinding effect that can be obtained in a short time.

Easy to clean and change color: After grinding, raise the grinding basket above the liquid level, run it for a short time, and use centrifugal force to throw out the residual material.

Product Advantages:

1. Dispersion and grinding in one, and the two processes are completed by one process and one equipment.

2. Due to the use of dispersion disc and pump blade, materials with high viscosity also have a good flow rate.

3. Easy to clean grinding basket, can quickly change materials.

4. No need for pumps and pipelines.

5. The pump blade with hydrodynamic design is used to ensure that there is no dead angle in the production process.

6. The proprietary wire cutting molding technology increases the flow area of the screen plate by 30% and reduces the resistance by 60%, which is convenient for the precise separation of grinding medium and material.

7. Hydraulic, pneumatic and mechanical lifting can be adopted according to user requirements, and the frame runs reliably and smoothly.

8. Frequency conversion control, which can realize stepless speed regulation.

9. Reliable results can be obtained in a short time.

host X1, manual X1, certificate X1, warranty card X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
