CHNSPEC EX Pro printing density meter Handheld Dual caliber High Accuracy Color Management
Adopt dual-row High Accuracy CMOS array Sensor, density Repeatability ≤ 0.001D, chroma Repeatability dE * ab ≤ 0.03. Provide horizontal press measurement and physical positioning observation window, support nearly 30 kinds of Measurement parameters and more than 30 kinds of evaluation Illuminants, to meet the needs of accurate color analysis in Offset Printing, Gravure Printing and other processes.
CHNSpec
EX Pro
-
Shangtian Jingyi AE124J density Electronic Balance Solid liquid density scale 120g/0.1mg
$ 948.00 -
XIONGFA XF-300S Solid Density Meter Liquid Density Scale 0.001g~ 300g
$ 521.00 -
Shangtian Jingyi YM1003J density Electronic Balance specific gravity Balance 100g/0.001g
$ 820.00 -
INESA WMD-430 automatic density meter U-tube vibration principle 2~ 3ml injection
$ 8968.00 -
FANGRUI Instrument ZMD-1 Electronic Density Meter density range 0~300g/cm3
$ 612.00
Product Introduction
EX Pro handheld print density meter is designed for the printing industry, which can accurately measure the color density of various printing processes such as offset printing and gravure printing, and quickly obtain data, helping practitioners effectively control color quality and correct deviations in time. Its handheld design is lightweight and portable, providing reliable color management support anytime, anywhere, ensuring consistent printed colors.
Features:
1. Ultra-high repeatability: density value: ≤0.001D, chromaticity value: dE*ab≤0.03
2. Horizontal pressure measurement, physical positioning observation window
3. Provide special measurement indicators for printing to help users adjust colors efficiently
4. Dual caliber design to meet the measurement of samples of different sizes
5. Use the powerful PC-side color management system ColorExpert
6. Nearly 30 measurement parameters and more than 30 evaluation light sources
7. Support connecting to mobile APP and WeChat mini program
CHNSpec EX Pro Printing density meterSpecifications
| LIST | VALUE |
|---|---|
| Measurement/Lighting Aperture | Φ2mm/5mm，Φ1.5mm/3mm |
| Battery capacity | Single charge can be continuously measured 8000 times, 7.2V/3000mAh |
| interface | USB, Bluetooth |
| Density range | 0.0 D – 3.0 D |
| Density standard | Status A, E, I, T ,M |
| Meet the standard | ISO 5-4:2009(E), ISO 13655:2017,CIE No.15 |
| Instrument display | Full-color screen, 3.5 inches |
| Supported languages | Simplified Chinese, English |
| Illuminant | Full Band Balanced LED Illuminant + UV |
| Measurement mode | M0, M1, M2, M3 |
| Measurement structure * | 45/0 |
| Measurement time | Approximately 1.5 seconds |
| Measurement Repeatability ** | Density value: ≤ 0.001D, chromatic value: dE * ab ≤ 0.03 |
| wavelength interval | 10nm |
| Wavelength range | 400-700nm |
| Illuminant life | 10 years 1 million times |
| storage | Instrument: 100 master standards, 10,000 samples; APP: mass storage |
| spectroscopy | grating |
| Sensor | High Accuracy CMOS Array Sensor |
| Reflectance measurement range | 0-200% |
| Reflectance resolution | 0.01% |
| Software support | Android, iOS, Windows, WeChat Mini Program |
| Accuracy Guarantee | Guaranteed Level 1 Measurement Qualification |
| Inter-instrument Agreement *** | dE*ab≤0.3 |
| Display accuracy | Density value: 0.001, chromatic value: 0.01 |
| Field of view | 2°，10° |
| Measurement index | CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB, color difference (delta E * ab, delta E * cmc, delta E * 94, delta E * 00), Blackness (My, dM), colour fastness, discoloration fastness, Tint (ASTM E313-00), colour density CMYK (A, T, E, M), Metamerism index Milm, Munsell, hiding power, force (dyestuff strength, Tinctorial Strength) |
| Printing quality indicators | Color density CMYK (A, T, E, M), Dot area, Dot area increase, Overlay rate, Print Contrast, gray scale, shading error |
| Illuminant condition | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1, LED-V2 |
| Note | * 45 degree circular illumination/0 degree angle reception ** Whiteboard calibration after 5 seconds interval measurement whiteboard 30 times Standard Deviation (except M3) ** * BCRA series ⅱ 12 swatches M0 mode 5mm diameter measurement average (except M3) |
CHNSpec EX Pro Printing density meter Packing list
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
