HuiNuo SZQ-100 20/30/60/80μm 4-sided Applicator 100mm Spreader Width +/- 2μm accuracy
High hardness 9Cr18Mo stainless steel material, wear resistance and corrosion resistance, hardness of 50~ 55HRC. Accuracy up to +/- 2 microns, Spreader width 100mm, support non-standard customization, can be used with Automatic Film Applicator.
HuiNuo
SZQ-100 20/30/60/80μm
-
HuiNuo SZQ-150 200/400/600/800 4-sided Applicator
$ 261.00 -
CHINA SZQ-75 single-sided wet-Film Applicator, scraping film thickness 75μm application width 75mm
$ 159.00 -
MODERNER SZQ 300 Wet Film Applicator 300μm/160mm Film Width
Login -
JINGKELIAN KTQ-250 (316) adjustable laboratory Film Applicator 316 stainless steel material application width 250mm
$ 545.00 -
MODERNER SZQ 400 GB paints Coating Applicator 400μm/160mm
Login
Product Introduction
The four-sided applicator is an experimental coating device with an accuracy of ±2 microns, with two coating widths of 80 and 160mm, and is made of high-carbon-chromium wear-resistant stainless steel, which has good corrosion resistance. The wet film preparation machine will be tested for accuracy before leaving the factory, using imported three-coordinate testing, and with a factory testing data report, which can withstand measurement. SZQ four-sided film applicator is suitable for sample film proofing in resins, coatings, glues, new materials, polymer materials, and other fields. Support non-standard customization. It can also be equipped with laboratory automatic coating machine for automatic coating.
SZQ-100 20/30/60/80μm is an extended four-sided preparer with a coating thickness of 20μm, 30μm, 60μm, and 80μm, and a coating width of 100mm.
Product features:
1. 9Cr18Mo high-hardness stainless steel, with good wear resistance and corrosion resistance, hardness value up to 50~55HRC.
2. The accuracy is up to ±2μm to ensure the accuracy of the experiment
3. The surface is smooth, the style is diverse, the application range is wide, and customized specifications are supported
4. Adopt imported three-coordinate testing accuracy, bring factory test report, and stand up to measurement
Preparer series parameter table
| Name | Specification mm | Wet film thickness μm |
| Single-sided prep | The total length is 80, and the coating width is 50 and 75 | 50、75、100、125、150、175、200 |
| Duplex prep | Total length 100, coating width 80 | 25、50、75、100、150、175、200、300、400 |
| Frame preparer | Total length 90, coating width 80 | 30、50、60、90、120、150、200 |
| Eight-sided preparer | Total length 90, coating width 68 | 50、75、100、125、150、175、200 |
| Eight-sided preparer | Total length 100, coating width 80 | |
| Square preparer | 25x25, coating width 16 | 37、50、75、100 |
| Square preparer | 50x50, coating width 41 | 50、100 |
| Standard four-sided preparer | Total length 100, coating width 80 | All specifications and sizes support non-standard customization |
| Extended four-sided preparer | Total length 190, coating width 160 |
HuiNuo SZQ-100 20/30/60/80μm 4-sided ApplicatorSpecifications
| LIST | VALUE |
|---|---|
| type | 4-sided |
| wet film thickness | 20/30/60/80μm |
| Spreader Width | 100mm |
| accuracy | ±2μm |
| material | 9Cr18Mo stainless steel |
HuiNuo SZQ-100 20/30/60/80μm 4-sided Applicator Packing list
Applicator x1, test report X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
