APPLENT AT4204 Handheld multi-channel temperature Tester 4 channels, touch screen control
APPLENT AT4204 hand-held multi-channel temperature Tester is a 4 Number of channels portable multi-channel temperature Tester, the test range is -200~1300 ℃, AT4204 is suitable for home appliances, motors, electric appliances, thermostats, transformers and other multi-point temperature test.
Applent
AT4204
-
Liquid thermometer TQC TE0027 high-precision precision liquid thermometer
$ 291.00 -
Wasites WT200-24 Intelligent 24-channel temperature Recorder 24-channel temperature Recorder Linear dispersion instrument
$ 1159.00 -
Huazhike WT100P-48 Multi-channel temperature Recorder, temperature recording Linear dispersion instrument 48-channel Linear dispersion version
$ 1027.00 -
Handheld industrial thermometer HB6801 Hypertherm with K-type Thermocouple
$ 100.00 -
HANNA HI98517 Temperature Meter -40~550 ℃
$ 240.00
Introduction
AMBER AT4204 handheld multi-channel temperature Tester adopts high-performance 32-bit ARM microprocessor control, which can collect multi-channel temperature data at the same time, alarm and communication transmission, compatible with a variety of temperature sensors, fast response, stable data, and has the function of broken detection. Ultra-low power consumption design and high-density SMD assembly process, true color TFT LCD display, and with keyboard, touch screen dual control. Powered by lithium battery, USB communication. The operation interface between Chinese and English can be quickly switched. The standard data acquisition software provides you with strong support for data analysis!
Performance characteristics
● TFT true color LCD display
● Touch screen control
● Fast, medium and slow three-level scanning speed
● Cold junction compensation
● Standard USB disk interface, supporting large-capacity storage devices
● Standard MiniUSB interface
● Automatic detection of broken couples
● Designated channel scanning
● ATS48 data acquisition software is standard
● Powered by 8.4V lithium battery
Application
● It is suitable for multi-point temperature testing by manufacturers and quality inspection departments of home appliances, motors, electric heating appliances, thermostats, transformers, ovens, thermal protectors, power supplies, lighting, electric power, LEDs and other industries.
Amber Multi-way Temperature Tester Selection Table
Applent AT4204 Multichannel temperature TesterSpecifications
| LIST | VALUE |
|---|---|
| indexing mark | Thermocouple: J/K/T/E/S/N/B/R type |
| Basic Precision | 0.2 ℃ +/- 2 characters (excluding Thermocouple) |
| Temperature Measurement Range | -200~1300℃ |
| resolution | 0.1℃ |
| Number of channels | 4 channel |
| Sampling rate | Fast: 100ms Medium speed: 500ms Slow speed: 1s |
| correction | error correction per channel |
| comparator | Up and down super alarm |
| Interface | Mini-USB, charging interface, TF card interface, U disk interface |
| Standard software | ATS42 data collection software |
| cold junction compensation | Precision: 0.5 ℃ |
| other | 2.8-Inch true color 16M color TFT-LCD display; touch screen; USB communication, compatible with SCPI Instruction Set Architecture; Chinese and English switching; backlight adjustment; Timer shutdown, support TF card storage and USB disk storage |
| Power Supply | Input: 100-240V~ 50/60Hz 0.35A Output: 9V 1A DC |
| Power Supply | 8.4V, Li, 1400mAh rechargeable battery |
| Power Supply | Charging time: 200Min max. |
| Battery life | Luminance 30% ≥ 14 hours, luminance 50% ≥ 12 hours, luminance 100% ≥ 9 hours |
| Dimension | 90*190*31mm |
| Weight | 400g |
Applent AT4204 Multichannel temperature Tester Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
