Introduction
JIAHANG JH50 Video Melting Point Tester is a semi-automatic video melting point Tester for fats and oils. It combines high-precision temperature control technology and high-definition video camera technology. It not only provides users with accurate, stable and reliable feel. The high-definition video can easily and clearly see the whole process of sample melting, which is convenient for users to accurately measure the melting point and melting distance of the sample. JH50 Video Melting Point Apparatus has dual video functions of taking photos and video recordings, without map saving function, and can store 400 data.
field of use
JH50 Video Melting Point Apparatus plays an important role in the chemical industry and pharmaceutical research, and is the required instrument for the production of food, medicine, spices, dyes and other organic crystal substances.
Back interface details
Some app users
★Shanghai Institute of Organic Chemistry, Chinese Academy of Sciences; ★Shanghai Institute of Materia Medica, Chinese Academy of Sciences; ★Jilin Institute of Materia Medica;
★Nanjing University; ★Chinese University of Hong Kong; ★Harbin Institute of Technology;
★ Ximeng Food and Drug Inspection and Testing Center; ★ Yangzhou Zhonghui Pharmaceutical Co., Ltd.; ★ Guangxi Wuzhou Pharmaceutical (Group) Co., Ltd.; ★ Northeast Pharmaceutical Co., Ltd.;
★Zhejiang Transfar Co., Ltd.; ★Jiangsu Jihua Chemical Co., Ltd.; ★Jinghai County Fuming Resin Co., Ltd.; ★Jiangxi Ji’an Xiajiang County Hengtong Auxiliary Co., Ltd.;
★Shanghai Pauway Bio-Pharmaceutical Co., Ltd.; ★Kerisley Biotechnology Beijing Co., Ltd.; ★Hainan Dachuan Food Co., Ltd.; ★Dalian Fine Petrochemical Co., Ltd.;
JIAHANG JH50 Melting point MeterSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | RT+~400°C |
| temperature resolution | 0.1℃ |
| Heating rate | 0.1~ 20 ℃ (200 gears, stepless adjustable) |
| Error of indication | ±0.3℃(<250℃)；±0.5℃(>250℃) |
| Sexual repeability | ±0.1℃(0.1℃/min) |
| Capillary size | Outer diameter Φ1.4mm; Inner diameter Φ1.0mm |
| Display | TFT high-definition true color screen |
| Data Interface | USB RS232 network port |
| magnification | 7X |
| processing power | 4 pcs/batch (four samples can be made at the same time) |
| user management | 8 |
| Video function | Take pictures, take pictures |
| Video playback function | Yes. |
| Graph storage | without |
| data storage | 400 |
| Video storage | 8G |
| Experimental method Storage Capacity | without |
| Power | 220V 50HZ 120W |
JIAHANG JH50 Melting point Meter Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
