HUITAI BPG-9240A precision blast drying oven volume 225L drying/sterilizing/baking

Volume 136L, Temperature range RT + 10~ 300 ℃, Temperature Fluctuation +/- 0.5 ℃, using fan speed Control mode, with over temperature deviation protection, digital display.

Brand

SKU: NB006935

HuiTai

Model

BPG-9240A

Price

$ 1030.00

Promotion

Service

The delivery and service By NBchao.Com

Get Quote

HuiTai shopSE

Information

Datasheet RFQ Contract Catalog

What else did others buy

YIHENG BPZ-6503LC Vacuum Oven (formerly BPZ-6500LC)

$ 10536.00
HUITAI GRX-9073A Hot Air Sterilizer, Volume 70L

Login
Kenton DHG-9130C electric thermostatic drying oven 130L with independent temperature limiter

$ 647.00
RONGHUA DZF-6090 Vacuum Oven 50~250 ℃

$ 1563.00
SANFA DHG-9070 Electric thermostatic Drying Oven 70L

$ 388.00

Genuinegoods

HuiTai BPG-9240A Precision blast Drying OvenOverview
Specifications
Comments
FAQs

BPG-9240A

Precision blast Drying Oven

Volume 136L, Temperature range RT + 10~ 300 ℃, Temperature Fluctuation +/- 0.5 ℃, using fan speed Control mode, with over temperature deviation protection, digital display.

Applications

Huitai BPG-9240A precision Forced Air Drying Oven is suitable for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.

Features

1. Large-screen LCD display, multiple sets of data displayed on one screen, menu-style operation interface, easy to understand and easy to operate. (standard configuration)

2. The fan speed control mode is adopted to improve the temperature uniformity of the working room.

3. The self-developed air duct circulation system is adopted to automatically discharge the water vapor inside the box, and there is no trouble of manual adjustment.

4. It adopts a microcomputer temperature controller with over-temperature deviation protection and digital display, with timing function, and the temperature control is accurate and reliable.

5. The inner tank is made of mirror stainless steel, the shelf bracket can be installed and disassembled freely, and the semi-circular four-corner design makes cleaning more convenient.

6. The Oven Casing is made of high-quality cold-rolled steel plate, and the surface is electrostatically sprayed.

7. Independent temperature limit alarm system, which will be automatically interrupted when the temperature exceeds the limit, so as to ensure the safe operation of the experiment without accidents. (optional)

8. With RS485 interface, it can be connected to the Recorder and computer, and can record the changes of temperature parameters. (optional)

Optional

Intelligent program controller

Independent temperature limit controller

Embedded printer

RS485 interface and special software

Test hole 25mm/50mm

Comparison of parameters of BPG series precision Forced Air Drying Oven

project	BPG-9070A	BPG-9140A	BPG-9240A	BPG-9420A	BPG-9620A	BPG-9920A
Voltage	AC220V 50HZ
Temperature control range	RT+10~300℃
Constant temperature fluctuation	±0.5℃
temperature resolution	0.1°C
input power	1100W	1550W	2050W	3500W	4000W	5000W
Studio size W×D×H(mm)	400×425×445	450×550×550	500×600×750	600×550×1300	800×640×1280	1000×600×1600
Dimensions W×D×H(mm)	545×580×800	640×710×905	680×800×1205	780×750×1850	960×750×1750	1180×800×2150
volume	80L	136L	225L	420L	620L	1000L
Carrier (standard)	2pcs			3pcs	4pcs
Timer Range	1~9999min
*Performance parameter test under no-load conditions, no strong magnetism, no vibration: ambient temperature 20°C, ambient humidity 50%RH.

HuiTai BPG-9240A Precision blast Drying OvenSpecifications

LIST	VALUE
Power	AC 220V 50Hz
Temperature range	RT+10~300℃
Temperature Fluctuation	±0.5℃
Temperature Resolution	0.1℃
Input Power	2050W
Interior size	500600750mm
Dimensions	6808001205mm
Volume	225L
Shelf (std.)	2pcs
Timer	1~9999min

HuiTai BPG-9240A Precision blast Drying Oven Packing list

host X1, fuse X2, rack X2, certificate X1, manual X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

We need a drying oven mainly for drying samples and sterilizing. Which model do you recommend?

[A]

HUITAI BPG-9240A precision blast drying oven is recommended. It features an air duct circulation system that automatically discharges water vapor and has good temperature uniformity, making it suitable for sample drying and sterilizing applications. The liner mirror stainless steel material is also easy to clean and maintain.

[Q]

Our R & D institution needs to do material baking experiments, and the temperature accuracy requirements are relatively high. Is this suitable?

[A]

Suitable. BPG-9240A Temperature Fluctuation +/- 0.5 ℃, resolution 0.1 ℃, accurate and reliable temperature control. It also has over-temperature protection function to ensure experimental safety, suitable for R & D institutions with high temperature accuracy requirements for material baking experiments.

[Q]

Do you have the precision blast drying oven involved in JB/T5520?

[A]

The BPG-9240A precision blast drying oven can

[Q]

This drying oven can control the temperature of 125 ° C and can hold 200L?

[A]

BPG-9240A Precision blast drying oven Temperature range 10~ 300 ℃, effective volume 225L meet.
