BOXUN CY50 Thermostatic Oil Bath temperature control accuracy +/- 0.1 ℃
BOXUN CY50 Super Thermostatic Oil Bath is a horizontal thermostatic Oil Bath, Temperature range is room temperature~ 300 ℃, CY50 opening size is 250 × 180mm, with insulation layer.
Boxun-
CNSHP CH3006 Laboratory Thermostatic Bath Temperature range + 30~300 ℃
$ 826.00 -
Shangtian Jingyi DC-2015 Low Temperature Thermostatic Bath Digital Thermostatic Water Bath -20 ℃/15L
$ 1712.00 -
YIHENG MPE-50C low temperature circulating Water Tank -50~100 ℃/4.5L
$ 2926.00 -
NELE NLSC-20D super thermostatic Bath (Water/Oil), Circulating Bath (Water/Oil) 20L/300 ℃
$ 837.00 -
NELE DC-6015 Thermostatic Bath Vertical 15L/-60 ℃ +/- 0.05 ℃
$ 5182.00
CY20 super constant temperature oil tank is made of imported stainless steel plate and professional technology, and all technical indicators have reached the national standard, which is the replacement product of constant temperature Water Bath. It has the advantages of high temperature control accuracy, strong corrosion resistance, compact structure, beautiful appearance, energy saving, long service life, etc., and is selected for precision products in the fields of biology, physics, plants, chemical industry, environmental protection, etc.

Features
It has a professional internal circulation/external circulation pump system, the internal circulation ensures that the temperature is uniform and constant, and the external circulation pump can lead the heated liquid in the tank to the heating or thermostat outside the experimental container;
0.1 accuracy is LED double window digital display temperature measurement value and temperature set value, 0.01 accuracy is LCD liquid crystal display, touch button operation is convenient;
Correction of deviation of measured value;
The insulation layer adopts effective insulation materials, which is more convenient for customers to use for a long time;
Desktop structure, beautiful and generous appearance;
In the limited space, the use function of the product is greatly increased, and the flow rate of the Circulating Chiller is ≥ 8 liters/min, the outer diameter of the outer circulation inlet and outlet is 10mm, and the inner diameter is 8mm.
Parameters
Model | CY20 | CY20A | CY30 | CY30A | CY50 | CY50A | |
Product type | Super sump | ||||||
Temperature range | Room temperature ~300°C | ||||||
Circular method | Inner Circulation (Outer Circulation) | ||||||
precision | ±0.1℃ | ±0.01℃ | ±0.1℃ | ±0.01℃ | ±0.1℃ | ±0.01℃ | |
Volatility | ±0.1℃ | ±0.05℃ | ±0.1℃ | ±0.05℃ | ±0.1℃ | ±0.05℃ | |
Uniformity | ±0.1℃ | ±0.03℃ | ±0.1℃ | ±0.03℃ | ±0.1℃ | ±0.03℃ | |
Heating power | 1500W | 1800W | |||||
Pump flow rate | ≥8L/min | ||||||
Opening size(mm) | 200×180 | 250×180 | |||||
Working size(mm) | 400×280×180 | 400×300×250 | 400×350×350 | ||||
Dimensions(mm) | 460×400×350 | 460×420×420 | 460×420×520 | ||||
power supply | 220V 50Hz | ||||||
Boxun CY50 Thermostatic Oil BathSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | RT+~300℃ |
| Temperature Fluctuation | ±0.1℃ |
| Temperature Resolution | 0.1℃ |
| Tank opening Dimensions | 250*180mm |
| Circular mode | Internal/external circulation |
| Total Power | 1800W |
| Power supply Voltage | 220V 50Hz |
| Dimensions | 460*420*520mm |
| Flow rate of pump | ≥8L/min |
| Tank Size | 400*350*350mm |
| Temperature control Accuracy | ±0.1℃ |
| Temperature Fluctuation | ±0.1℃ |
Boxun CY50 Thermostatic Oil Bath Packing list
machine X1, manual X1, certificate X1, warranty card X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
FAQ
- ActiveJJF 1030-2010
- ActiveHG/T 3660-1999
- ActiveJB/T 9518-1999
- ActiveGB 9278-2008
- ActiveGB/T 5561-2012


CY50
