BOZHEN 101-4 Electric Forced Air Drying Oven Operating temperature 50~300 ℃ Power 7KW
Rated power of BOZHEN Electric Forced Air Drying Oven 101-4 is 7KW, temperature can reach 300 ℃, 101-4 is desktop Drying Oven, Interior size is 800 × 800 × 1000mm.
BoZhen
101-4
Product Applications
101-4 electric Forced Air Drying Oven is for industrial and mining enterprises, laboratories, scientific research units, etc. for drying, baking and melting wax, heat treatment and other heating, not suitable for the drying of flammable and explosive materials, so as not to cause explosion.
Features
1. The temperature control adopts pointer instrument temperature control, which is simple to operate, the box body is made of arc argon welding, the box is made of good steel plate, and the inner tank is sprayed with high-temperature silver paste, which is corrosion-resistant and high-temperature resistant. The design and color are synchronized with the international level, and the shape is more beautiful and novel.
2. Built-in circulating ventilation makes the temperature more uniform
3. It is equipped with a tempered glass door, which can clearly observe the changes of the sample and does not affect the temperature loss.
Execution targetpermit
JB/T5520 "Technical Conditions for Drying Ovens" national industry standard.
Display diagram
BoZhen 101-4 Forced Air Drying OvenSpecifications
| LIST | VALUE |
|---|---|
| Temperature range | RT+50~300℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Resolution | 1℃ |
| Temperature Uniformity | ±2.5°(100℃) |
| Power supply Voltage | 220V |
| Input Power | 7000W |
| Interior size | 800*800*1000mm |
| Dimension | 1020*1240*1410mm |
| Chamber material | steel plate |
BoZhen 101-4 Forced Air Drying Oven Packing list
host X1, operation manual X1, warranty card X1, certificate of conformity X1
[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
